| Categories | Carbon Steel Pipe |
|---|---|
| Brand Name: | NO |
| Model Number: | 2inch -8inch |
| Certification: | API, ISO |
| Place of Origin: | China |
| MOQ: | 1pc |
| Price: | Negotiation |
| Payment Terms: | L/C, T/T |
| Delivery Time: | 30-60 days |
| Packaging Details: | in bundle |
| Thickness: | 3.91-7.11mm |
| Length: | 6m |
| Surface: | Black painted |
| Usage: | water well |
| Grade: | API 5 L GRADE B |
| Technique: | seamless steel pipe |
| Company Info. |
| Henan Wein Industry Co., Ltd. |
| View Contact Details |
| Product List |
Small Diameter 3 Inch Seamless Cs Pipe Astm A53 Grade B SCH40 Thickness
Description of Carbon steel seamless pipe API 5L Grade B of 3 inch seamless steel riser pipe for well
Size:2inch-8inch
Grade:API 5L Grade B
Standard: ASTM A 53 GRADE B OR API 5L GRADE B
Thicknee:SCH40
Length tolerance:-0/+100mm
Condition: Seamless steel pipe,
Length of coupling: min 200mm
Taper:3/4 inch per foot
Technical data:
| Size | WT (SCH40) | Length End of pipe to Hand tight plane L1 (mm) | Length Effective Thread L2 (mm) | Total length End of pipe to vanish point L4 (mm) | Number per inch | Minimum length, full Crest Threads from end of pipe LC (mm) | End of pipe to Center of Coupling, Power-Tight Make-Up J (mm) | Length NL (mm) |
| 2”(60.33) | 3.91mm | 24.86 | 36.9 | 42 | 10 | 19 | 12.7 | 203 |
| 3”(88.9) | 5.49mm | 42.5 | 48 | 58.75 | 8 | 35.9 | 12.7 | 203 |
| 4”(114.3) | 6.02mm | 48.8 | 68.96 | 76.2 | 8 | 47.625 | 12.7 | 203 |
| 5”(141.3) | 6.55mm | 61.5 | 81.66 | 88.9 | 8 | 60.325 | 12.7 | 203 |
| 6”(168.28) | 7.11mm | 70.45 | 90 | 97.6 | 8 | 69.025 | 12.7 | 220 |
Factory test and other terms:
1. Hydrostatic or Nondestructive Electric Test
2. Heat Treatment: according to Standard
3. Surface Condition:According to Standard.
4. Grain Size:According to standard
5. Sampling:flattening,flaring,grain size,Marking
6. we provide bevel end,plastic cap, varnish coating, oiled or black painted to prevent rustand other packing
service.
|
