ARJM11A1-809-KK-CW2 RJ45 Single Port 1x 2.5G Mbps Ethernet Connector
- RJ45 1x 2.5G Mbps Ethernet Latch-down
- Angled Rj45 Connector 2.5G base-tx Ethernet
- Telecom transformers and RJ45 modules
- Without LED Indicator
Part Status | Active | |
---|
Connector Type | RJ45 | |
---|
Number of Ports | 1 | |
---|
Number of Rows | 1 | |
---|
Applications | 2.5G Base-T, AutoMDIX | |
---|
Mounting Type | Through Hole | |
---|
Orientation | 90° Angle (Right) | |
---|
Termination | Solder | |
---|
Height Above Board | 0.535" (13.59mm) | |
---|
LED Color | Green, Orange - Green, Orange | |
---|
Number of Cores per Jack | 8 | |
---|
Shielding | Shielded, EMI Finger | |
---|
Features | Board Lock | |
---|
Tab Direction | Down | |
---|
Contact Material | - | |
---|
Contact Finish | Gold | |
---|
Operating Temperature | 0°C ~ 70°C | |
---|
Contact Finish Thickness | 6.00µin (0.152µm) |
---|
Applications For Terminal User
Designed to support applications, such as ADSL modems,
LAN-on-Motherboard. Networking and communication equipments such as HUB, PC card,
Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem,Call Center solutions , Complex set top boxes , VOIP gateways
setup,Border Gateway Protocol,fast ethernet switch ...
Competitive Advantage
18 years production experience,
2600 staff,
100% test
Flexible delivery time
Main Customer
Design for Ti , Intel , Samsung , Fluke , Jabil , Flextronics
,Cypress, Freescale,EKF.......


EMS ApplicationBuilt-in Flexible PCB Assembly; Rigid-Flexible PCB Assembly;
Microelectronic, Flip Chip; Microelectronic, Chip On Board;
Optoelectronic Assembly; RF / Wireless Assembly; Through Hole
Assembly; Surface Mount Assembly; System Assembly; Printed Circuit
Board Assembly
Other Part Number
ARJM11B1-805-NN-ER2-T | ARJM11A1-805-NN-ER2-T | ARJM11D7-809-NN-EW4 |
ARJM11C7-809-NN-EW4 | ARJM11D7-805-NN-EW4 | ARJM11C7-805-NN-EW4 |
ARJM11B3-809-AN-CW4 | ARJM11A3-809-AN-CW4 | ARJM11B3-805-AN-CW4 |
ARJM11A3-805-AN-CW4 | ARJM11B1-809-AN-CW4 | ARJM11A1-809-AN-CW4 |
ARJM11B1-805-AN-CW4 | ARJM11A1-805-AN-CW4 | ARJM11B1-805-KB-CW2 |
