| Categories | Explosion Proof Plug And Socket |
|---|---|
| Brand Name: | Natural |
| Model Number: | BJ-25YT/GZ-3 |
| Place of Origin: | china |
| MOQ: | 1 |
| Price: | USD+14.17-14.88+set |
| Payment Terms: | T/T |
| Supply Ability: | 500+SET+WEEK |
| Packaging Details: | 21CMX15CMX10CM |
| Product Name | Explosion Proof Plug Socket |
| Grounding | Yes |
| Model | BJ-25YT/GZ-3 |
| Material | Aluminum body and silver core |
| Color | Grey |
| Weight | 0.63KG |
| Warranty | 12month |
| Application | Oil,ex-proof,petrochemical industry,marine |
| Certification | ExdII |
| Protection level | IP54 |
| Place of Origin | China |
15A~200A YT/GZ,YZ series non-spark electric connector is suitable
for petroleum exploration,borehole electric control and other
electrical continuity,which comply with the relevant regulations is
National Standard GB3836.8-2003 & the provision of Europe Standard
EN60079-15:2005 “Electrical Apparatus for Explosive Gas Atmosphere
Part 8: Type of Protection'n'''.Explosion-proof sign is ExnAII
T4,EExnA II T4.
The electric connector consists of two parts:Plug&Socket, of
which the plug is mobile(YT).Three kinds of options are made
available in the sockets,namely,1 fixed socket(GZ),2 mobile
plug(YZ),3 title-type fixed socket(XGZ).Coupling way of the plug
and socket is soiral bayonet snap coupling.End connection form
between the contacts and wires is crimping.The contacts use elastic
rin to support positioning and re the structure of installing from
the rear and removing from the front.ZL-102 die-casting alloy is
applied in the connector assembly,the contact element is plated
with silver,which ensured reliable contact,convenient wiring,better
air tightness & insulation,together with such features are
waterproof,dust prevention,shockproof,etc.
Technical data:
Working voltage:AC220V,AC400V
Working current:15A,30A,60A,100A,150A,200A,300A
Life:1000times
Contact resistance:0.0008Ω
Insulation resistance:100MΩ
Insulation dielectric strength:2000V(220V),2500V(400V)
Protection degree:IP54
Single phase three wireconnector:YT/GZ-15A/25A/60A
Three phase four wire
connector:YT/GZ-15A/25A/60A/100A/150A/200A/300A
Three phase four wire connector
:YT/GZ-15A/25A/60A/100A/150A/200A/300A
|
