Place of Origin: | Anhui, China (Mainland) |
Brand Name: | JNTECH |
Model Number: | JNP7K5H |
Supply Ability: | 1000 Set/Sets per Month |
Packaging Details: | Each inverter packed in EPE foam case, then in standard exported carton |
MOQ: | >=2 Sets |
Price: | $1,000.00 |
Output Type: | Triple |
Size: | 420*310*229mm |
Weight: | 13.9kg |
Input Voltage: | 460-850Vdc |
Output Voltage: | 380-460Vac |
Type: | DC/AC Inverters |
Output Frequency: | 0-50/60Hz |
Output Current: | 18A |
Max. input voltage: | 1000V |
MPPT voltage: | 460-850Vdc |
MPPT effeciency: | >99% |
Display: | LCD Screen |
Protection: | IP65 |
Warranty: | 3 Years |
Color: | Blue |
Communication: | RS485/GPRS |
Certificate: | TUV&CE |
Output waveform: | Midified Sine Wave |
Port: | SHANGHAI/NINGBO/GUANGZHOU |
Company Info. |
JNTECH RENEWABLE ENERGY CO.,LTD |
View Contact Details |
Product List |
Jntech solar pump inverter ranges from 370W to 132kw for driving any single phase , three phase submersible pump or surface pump. All Jntech solar pump inverter adopts advanced IGBT power module design, takes advanced MPPT technology caculation, effeciency is more than 99%. Low temperature rise, low noise ,long life span, perfect system protection, high reliability, 3 years warranty and good service wins clients trust and good feedback.
Model | JNP2K2H | JNP3KH | JNP3K7H | JNP4KH | JNP5K5H | JNP7K5H |
Max. Input Voltage | 880Vdc | |||||
MPPT Voltage | 460-850Vdc | |||||
Max. Input Current | 5A | 6.9A | 9A | 9A | 12A | 16.3A |
MPPT Effeciency | 99% | |||||
Output Power | 2.2kw | 3kw | 3.7kw | 4kw | 5.5kw | 7.5kw |
Output Voltage | 380-460Vac , ( three phase 0-50/60Hz) | |||||
Output Current | 6A | 7A | 9A | 10A | 13A | 18A |
Max. Effeciency | 96% | 97% | 98% | 98% | 98% | 98% |
Weight | 13.9kg | |||||
size | 420*310*229 mm | |||||
Protection Level | IP65 | |||||
Operation Temperature | -25℃~ +60℃ | |||||
Communication | RS485/GPRS |
Working with high efficiency, even in high temperature 60 degree in Middle east or Africa in Summer. No stop working, no fault, no derate.
![]() |
