Brand Name: | YUANHAI |
Model Number: | YH-PFW |
Certification: | ISO9001 |
Place of Origin: | CHINA |
MOQ: | 10Sets |
Price: | $5.5-13.6/㎡ |
Supply Ability: | 5000Sets Per Month |
Packaging Details: | Powder Coated Frame Finishing And Fencing Trellis & Gates Type Palisade Fence Water Proof Paper+Pallet.Custom Packaging Is Also Available According To Your Details |
Material: | Pre Hot-dipped galvanized tube |
Frame Material: | Metal |
Frame Finishing: | Powder Coated |
Feature: | Easily Assembled, Eco Friendly, Renewable Sources, Rodent Proof, Waterproof |
Service: | 10 Years Of Export Experience, More |
Sample: | Free Of Charge |
Suggested Pale Thickness: | 2-6mm |
Height Above Ground: | 1-4.2m |
Company Info. |
Anping yuanhai wire mesh products Co., Ltd |
Verified Supplier |
View Contact Details |
Product List |
Galvanized Pvc Coated Metal Palisade Fence / Euro Fence / Garden Fence
Steel Palisade Fence Specification
1. Type Standard Configuration | ||||
Panel Height | Pales | O/C Spacing | Rails | |
8 | 13 ga. | 5-15/16" | 2" TS x 14 ga. | |
10 | 13 ga. | 5-15/16" | 2" TS x 14 ga. | |
12 | 13 ga. | 5-15/16" | 2" TS x 14 ga. | |
2. Type Standard Configuration | ||||
Post | Optionally available with base plates for bolt-down or cranked over walls. Also available with bracket extensions for barbed wire or razor wire. Size: 100 x 55mm/100 x 44mm | |||
Rails | Steel angle rails punched for pale attachment. Connected with 12mm square cup bolts and anti-vandal permacone (snap-off) nuts. Size: 40mm x 40mm/ 45mm x 45mm/ 50mm x 50mm | |||
Pale tops | Split-tripple point or single point for high security. Rounded or rounded and notched for ety. | |||
Fittings | Rails and pales are fitted using 'rivets & collars' or rounded bolts with permacone nuts (snap-off / anti-vandal). | |||
Link Plates | Link plates, AKA 'Fish Plates' fit through the holes is the steel fencing posts and join the rails together. |
Steel palisade fencing Finishes
Available as 'Hot Dipped Galvanised' or 'Galvanised & Polyester Powder Coated to any colour'.
![]() |
