Microwave doppler sensor digital microwave motion sensor module for sale
Antenna head ANT03 is just for you to do that as the crucial component for lighting and other intelligent products.
Description:
Customized service for you all the time.
Features:
1. Small Size: 32.5*22.5*12mm
2.
Operation voltage: | 5V DC |
Operation current: | 15mA |
Operation temperature: | -20-+75 |
Warming-up time: | 20s |
Digital output: | 5v high low voltage |
3. 4 sensitivity level
Desciption V-Tune PIN Voltage Sensitivity level
Low sensitivity 0.00v-1.249v 25%
Medium sensitivity 1.25v-2.49v 50%
High sensitivity 2.50v-3.74v 75%
Test sensitivity 3.75v-5.00v 100%
![]() |
