1000 Watt Audio PA System Amplifier ±385mV Input Sensitivity Safety Operation

Categories PA System Amplifier
Brand Name: GLSPA
Model Number: GLS-A009
Certification: CE
Place of Origin: China
MOQ: 100pcs
Price: Negotiation
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs/month
Delivery Time: 20 working days
Packaging Details: 1 piece/box
material: metal
color: black
type: Professional Amplifier
Channels: 1
Rated Power Output: 1000W
speaker output: 70V, 100V & 4~16Ω
Input Sensitivity: ±385mV
Input Impedance: 20KΩ
Output Sensitivity: ±385mV
Output Impedance: 470Ω
dimension: 484*530*88mm
weight: 26Kg
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

1000 Watt Audio PA System Amplifier ±385mV Input Sensitivity Safety Operation


PA System Amplifier 1000 Watt Audio Professional Power Amplifier


* Rack mount amplifier in 3U type

* Rated power from 1000W to 1500W

* 70V, 100V and 4-16ohm speaker outputs

* Isolated transformer for human safety operation

* Balanced XLR type line input and unbalanced 1/4 inch TRS phone jack line input

* Balanced XLR type line output feeds to another power amplifier

* Reliable protection of over heat, over load, clip & short circuit

* Indications for power, signal, clip, protection and temp

* Excellent device of radiator cooling fanner that ensures working effectively


Optional


*DC 24V input available on less than 500W models

* Panel with/without handhold

* Faults monitoring module, it can output short circuit signal to achieve main/spare amplifier switch (Except for 1000W and 1500W)


ModelGLS-A009
Rated Power Output1000W
Speaker Outputs70V, 100V & 4~16Ω
Input Sensitivity & Impedance±385mV/20KΩ, Balanced XLR Input; 775mV/10KΩ, Unbalanced TRS Input
Output Sensitivity & Impedance±385mV/470Ω, Balanced XLR output; 775mV/470Ω, Unbalanced TRS output
Frequency Response50Hz~16KHz(+1dB, -3dB )
S/N Ratio>90dB
THDLess than 0.3% at 1KHz, 1/3 rated power
Ground LiftLift the earth line ground by switch GND/lift to "lift" position
CoolingFan automatically start up when temp reaches 55℃
ProtectionOver heat, over load, clip & short circuit
Power Supply~110V/60Hz or ~230V/50Hz or DC 24V
Power Consumption1500W
Weight26Kg
Dimensions484x530x88mm
Finish

Panel: aluminum plate, black

Case: Steel plate, black
