Multi Function Ultrasonic Welding Tool 5000W 220V/110V Low Power Consumption

Categories Ultrasonic Welding Tool
Brand Name: Rps-sonic
Model Number: rps-w20-329
Certification: CE
Place of Origin: China
MOQ: 1pcs
Price: Negotiable
Payment Terms: T/T, Western Union
Supply Ability: 200PCS/MONTH
Delivery Time: 5-8days
Packaging Details: WOOD BOX
Name: ultrasonic welding machine
Frequency: 20Khz
Power: 5000W
The height of the frame in max: 280mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Multi Function Ultrasonic Welding Tool 5000W 220V/110V Low Power Consumption

20khz ultrasonic welding machine 5000W with Multi function auto welding


WHAT IS ULTRASONIC WELDING?

Ultrasonic Welding Technology uses high-frequency vibrations (ultrasonic) to accurately seal two thermoplastic parts together in sub-second timeframe. Under precise pressure, the connection is sealed in less than 0.2 seconds.

Ultrasonic welding basic

The ultrasonic waves vibrate 10's of thousands of times per-second. This oscillation is transferred to a contact surface that is directly in contact with the plastic parts. Since the boundary of the welding area has a large acoustic impedance, it produces high temperatures. Plastic is a pretty poor conductor of heat and can't dissipate the heat before it changes the state of the plastic from solid to liquid. With a bit of pressure applied, this makes the two parts blend together as if they are a single piece of plastic. Once the ultrasonic signal is stopped, the parts become solid again. This is the magic that creates a weld between the two parts that is clean and very strong. The weld will have a strength that is close to that of the raw materials being formed together in an injection molding process.


Function

1. Frequency auto-chasing: intelligent control system, frequency auto tracking.

2. amplitude adjust Infinitely : amplitude adjust Infinitely , amplitude increase and decrease by 5%;

3. intelligent protection: frequency offset protection, output overloading protection, mold damage protection;

4. electrical components: all pneumatic components and main electronic components of the machine are imported from Germany and Japan;

5. fuselage structure: the frame of the machine adopt special steel structure and made by precision cast aluminum CNC machining processing , the frame is more precise and more stable

Parameter:

Frequency20KHz
Generator2000W/3000W/4000W/5000W
Welding modelTime model energy model, power model, depth model
Distance micro-adjustment20-100mm Precision:0.01 mm
The height of the frame in max280mm
Input Voltage220V/110V

Advantages:

The benefits of ultrasonic welding are that they produce lower production costs, they create a very effective bond with a high-quality seal that doesn’t require fillers, and they have faster welding times that most other traditional welding procedures.


• High strength welds

• No consumables—no fasteners or adhesives

• Fast—no cure or dry time. Welds in less than a second.

• Easily automated

• Clean and precise

• No ventilation needed

• Can vibrate contaminates out of packaging seals

• Provides tamper-proof hermetic seals

• Low power consumption—works in short bursts

• Great for volatile or heat sensitive products

• Uses standard electrical power (both 220v/110V)

• Established technology with many choices in equipment

• Relatively low capital equipment costs
