| Categories | Household Heat Pump |
|---|---|
| Brand Name: | Yushen |
| Model Number: | SLNA-009U(P) SLNA-014UP |
| Certification: | CCC, ISO, CQC |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 10 sets/day |
| Delivery Time: | 1-2weeks |
| Packaging Details: | Reinforced Carton box with wooden tray |
| Key word: | Residential Air Source Heat Pump |
| Other name: | Split System Heat Pump |
| Function: | Air conditioning heating or cooling |
| Feature: | Space Saving |
| Suitable working conditions: | -25C~+45C |
| Electricity: | 220V-3N-50hz |
Space Saving Residential Air Source Heat Pump , Split System Heat Pump
Residential Air Source Heat Pump characters
1: Safety operation, no need to be on duty
Compared with gas and coal fired boilers, commercial air-energy heat pumps operate absolutely safety, reducing risks such as, boiler explosions and air leaks, and are intelligently controlled, eliminating the need for dedicated personnel and reducing expenses.
2: High heating efficiency
They can be widely used in hospitals, restaurants, hotels, playgrounds, villas,office building, hotels and other building heating and air conditioning
3. Low operating costs
The energy efficiency ratio of the water source high temperature unit is greater than 4.5, and the operating cost is 1/4-1/3 of the general heating mode, which is obviously lower than that of fuel oil and central heating.
Residential Air Source Heat Pump Parameters
| Model | SLNA(B)-014U(P) | |||
| Compressor capacity | 5HP | |||
| Function | Heating and Cooling | |||
| Electricity | 220V-1N-50Hz | |||
| Working conditions | ℃ | -25~～+45 | ||
| Data | Heata | Nominal capacity | KW | 9.2 |
| Input power | KW | 3.96 | ||
| COP | / | 2.3 | ||
| Heating IPLV(H) | 2.6 | |||
| Coolb | Nominal capacity | KW | 11.0 | |
| Input power | KW | 4.31 | ||
| COP | / | 2.55 | ||
| Cooling IPLV(C) | 2.75 | |||
| A7W35c | KW/COP | 14.0/4.1 | ||
| A2W35 | KW/COP | 11.2/3.60 | ||
| A-7W35 | KW/COP | 9.5/3.0 | ||
| A-15W55 | KW/COP | 8.4 /1.94 | ||
| A-20W45 | KW/COP | 7.7/2.00 | ||
| Max. running currency | A | 30 | ||
| Compressor quantity | set | 1 | ||
| Refrigerant/charging quantity kg | / | R22/4.50 | ||
| Air blow type | / | Side | ||
| Water pipe diameter | inch | G1.2〞 | ||
| Rating flow | m³/h | 2.5 | ||
| Water side pressure loss | kPa | ≤35 | ||
| Noise level | dB(A) | 61 | ||
| Overall dimensions(L×W×H) | mm | 1120×440×1360 | ||
| Weight | kg | 130 | ||
a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal heating capacity
b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity
c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃
|
