Ceiling Mount Outdoor Touch Screen Kiosk Android Advertising Player With Fans

Categories Outdoor LCD Display
Brand Name: ZXTLCD
Model Number: ZXT-CT430A-OT
Certification: CE/Rohs/FCC/ERP Energy Label
Place of Origin: China
MOQ: 1 piece
Price: Negotiate
Payment Terms: T/T,Western Union, Alibaba trade assurance
Supply Ability: 3,000 pcs per month
Delivery Time: 25 workdays
Packaging Details: wooden case, carton, flight case are option
Viewing Angle: 176(H)/176(V)
Material: 1.2-1.5mm metal plate
Version: Standalone / Android Network / PC(optional)
Interface: USB
OS: Android, Windows
Power plug: America standard, Europe standard
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Ceiling Mount Outdoor Touch Screen Kiosk Android Advertising Player With Fans

Shop Windows Touch Outdoor Kiosk Ceiling Mount Android Advertising Player With Fans


FC(Fan cooling) wall mounted and floor standing standard KIOSK Features:
1. 22" -32" Backlit: 1500cd / m2; ≥42 inch Backlit: 2000CD / m2; ≥70" Backlit: 2500CD / m2.

2.Glass: Anti-glare AR glass, use imported original film, AR anti-reflective T = 6.8MM, light transmittance 97%, reflectivity less than 3%,

with sandwiched glue.

3.Outdoor speakers: 8Ω 10W speakers.
4.Industrial power supply, automatic adjustment of brightness, reduce power consumption.

5.Humanized design: leakage protection switch + lightning protection device + time control switch (with leakage protection,

lightning protection, can set multiple groups of time control).

6.Scientific cooling: EBM centrifugal fan patented technology using intelligent temperature control system (with heating),

to meet the LCD screen working well in the external environment -40 to 55 degrees.

7.Outdoor professional chassis: galvanized steel plate + coated zinc powder + surface spray outdoor special powder

(outdoor anti-corrosion up to 10 years) + waterproof tape.

8.Professional outdoor test: IP65 waterproof test + high and low temperature test + simulated solar radiation test.

AC(Air conditioning) wall mounted and floor standing KIOSK Features:

1.22" -32" Backlit: 1500cd / m2; ≥42 inch Backlit: 2000CD / m2; ≥70" Backlit: 2500CD / m2.

2.Glass: Anti-glare AR glass, use imported original film, AR anti-reflective T = 6.8MM, light transmittance 97%, reflectivity less than 3%,

with sandwiched glue.

3.Outdoor speakers: 8Ω 10W speakers.
4.Industrial power supply, automatic adjustment of brightness, reduce power consumption.

5.Humanized design: leakage protection switch + lightning protection device + time control switch

(with leakage protection, lightning protection, can set multiple groups of time control).

6.Scientific cooling: intelligent industrial air conditioning patented technology All intelligent temperature control system (with heating),

to meet the LCD screen in the external environment -40 to 55 degrees.

7.Outdoor professional chassis: the use of galvanized steel + coated zinc powder base + surface spray for outdoor powder

(outdoor anti-corrosion up to 10 years) + waterproof tape;

8.Professional outdoor test: IP65 waterproof test + high and low temperature test + simulated solar radiation test.

The Product Specification :


Screen size55”
Active area size (W x H)1207X678mm
Aspect Ratio16:9
Panel resolution (pixels)1920X1080 (Full HD)
Luminance of white (Brightness)1000/1500/2000cd/m²
Contrast ratio5000:1
Response time5ms
Colour Range16.7 Million colours (max)
Viewing angle178° horizontal / 178° vertical
Video inputsVGA / HDMI
Audio InterfaceAUDIO IN/OUT
Auto Brightness ControlYes (Optional)
Temperature control systemIntelligent air conditioner or Fan is optional
Operating temperature range-40°C to +55°C
Storage Temperature0℃ to 50℃
Operating Humidity5% to100%
Input voltageAC 108-240 V, 50/60 Hz
Power Consumption0.8kW (Mainly for AC starting)
Waterproof EnclosureYes
IP ClassIP65
Enclosure materialMetal
Front glass typeStrengthen 6mm AR glass
TouchscreenInfrared Touchscreen or Capactive Touchscreen is Optional

Let us focus on full-outdoor LCD systems as they are trickiest to construct and/or purchase. Two biggest and tightly connected issues of engineering are stable sun readable performance and environment thermal management. Humans notice visible light sources (luminance) as brightness and perceive images as difference in shades, so to have great performance we need both, high brightness and as high as possible difference in black vs. white pixels.


While non-advertising based systems can afford lower performance specification it is preferable for units intended for outdoor advertising to have as high as possible brightness and contrast perfromance levels. For the best results in direct sunlight, the outdoor display should be able to continually operate at a minimum of 1.500 nits in bright sunlight with as high as possible contrast levels. It is a fact that also lower brightness (e.g. 700 nit) with high contrast LCD panels can deliver good sunreadability if properly hosted.


If you have any other questions, please contact our salesman as soon as possible.
