| Categories | Stainless Steel Investment Casting |
|---|---|
| Brand Name: | ABLINOX |
| Model Number: | ABL-SC01 |
| Place of Origin: | Foshan China |
| MOQ: | 20 |
| Price: | Negotiation |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 200 Ton/month |
| Delivery Time: | 35-40 days |
| Packaging Details: | PP bag/carton/plywood crate |
| Certification: | ISO9001:2015,CE |
| Product name: | Stainless steel Investment casting |
| usage: | Customized machinery |
| weight: | 0.1KG to 10KG |
| Material: | Stainless steel |
| Casting Standard: | GB,ISO, ASTM, AISI, DIN, etc |
| Surface Roughness: | Ra 0.4um-12.5um |
| Certificate: | ISO9001:2015 |
| Quality: | High end grade |
| Service: | OEM |
| Samples: | 25days |
Stainless Steel Investment Casting Of Machine Part Customized For Euro And USA Market
| Material | Stainless Steel ,316 316L 2205 |
| Processing | lost wax casting process + Precision CNC Machining + Surface Treatment |
| Casting process | Client drawings , pattern, raw casting, machining, packing and delivery |
| Surface treatment | Plating, anodizing powder coating, spray-paint, electrophoresis |
| Size | Customized as customer's drawings |
| Standards | DIN, AISI, ASTM, BS, JIS, etc |
| Service | To chart to sample production; OEM / ODM |
| Certificate | ISO9001:2015 |
| MOQ | Small order is acceptable |
| Shipping | Accept FOB or customer designated shipping agent |
| Package details | Standard export package(carton/wooden case/pallet) |
| Application | Machinery hardware,Auto hardware,Car hardware |
Stainless steel's biggest advantage is its excellent corrosion resistance. Unlike other materials, stainless steel investment castings have a built-in chromium oxide layer that provides exceptional anti-corrosive properties.
Applications
l Food processing machinery
l Pumps
l Valves
l Pipe Fittings
l Automotive
l Marine and Oil
l Machinery
l Power & Energy
l Mechanical Castings
Production Process
1.TOOL MAKING
A wax injection mold is designed and built to produce castings per
customer specifications.
2. WAX PRODUCTION
A wax pattern is produced from the wax injection mold.
3. PATTERN ASSEMBLY
Wax patterns are attached to gating system by hot knife.
4. SHELL MAKING
The pattern assembly is dipped into a ceramic slurry, coated with a
refractory material and dried. The process is repeated until the
desired thickness and strength is achieved.
5. DEWAXING
Using regulated steam pressure, an autoclave melts and remove the
wax from the ceramic shells.
6.SHELL PREHEAT
High temperature ovens cure and preheat the ceramic shells before
pouring.
7.CASTING
Pre-heated Ceramic cavities are poured with the molten metal.
8.KNOCK OUT
The ceramic shell is removed by vibration knocking and the cluster
is cleaned.
9.CUT OFF
Castings are cut off from the gating system.
10.MACHINING,SURFACE FINISH,AND INSPECTION
After cut off and gate removal, all secondary finishing operations
are performed. Each casting is inspected according to customer
specifications and requirements.
Equipments
With these in-house turning capabilities,We also can quote your bar stock requirements, which complements
our investment casting line.
We specialize in turning, drilling, tapping, and a variety of other machining capabilities to offer a complete product.
ABLinox can be your one-stop-shop and has in-house machining capabilities as well as outside machining services available for specialized machining.
ABLinox specializes in turning, drilling, tapping, and a variety of other machining capabilities to offer a complete product With these in-house turning capabilities, ABLinox also can meet your ready assembly product price requirements,which complements our investment casting line.
ABLinox have been cooperated with some TOP 500 enterprises in the world.
ABLinox wants to become a high-end customized expert in stainless steel industry.
ABLinox wants to be your first-grade partner in near future.
Our Service
l OEM & ODM lDrawing design lMould design l Investment Casting l Heat treatment
l Machining l Surface treatment l Assembly l Packing l Export & Trading to whole world
l Fast response within 24 hours l Project management l After-sales service
Quality inspection at each stage,
1. Incoming material inspection 2. Inspection of work-in-progress
3. Finished product inspection 4. Random warehouse inspections
|
