Categories | Custom Cs Carbon Steel Plate Sheets |
---|---|
Brand Name: | HDT |
Model Number: | ASTM A36, Q235B |
Certification: | ASME, GRADE A, ISO9001,ISO14001, PED |
Place of Origin: | China(Mainland) |
MOQ: | 5T |
Price: | 800 - 9000 USD / ton |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | About 10000 ton / month |
Delivery Time: | 60-75days |
Packaging Details: | seaworthy packing for exporting |
Material: | ASTM A36, Q235B |
Finishing: | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
Application: | boiler&heat exchanger, energy, petrochemical, mining, food, paper, gas and fluid industry |
Shape: | Steel plate or coil |
Company Info. |
ZHANGJIAGANG HUA DONG ENERGY TECHNOLOGY CO.,LTD |
Verified Supplier |
View Contact Details |
Product List |
8mm 10mm Thickness Steel Plates Astm A36 Standards Size 6000 mm x 2000 mm
Detailed Product Description
Width: | 100-2500mm | Grade: | Q235B A36 |
Technique: | Hot Rolled | Type: | Steel Plate |
Standard: | ASTM,AISI,JIS,DIN | Length: | 1000-12000mm |
Thickness: | 1mm-120mm | Shape: | Flat Steel Plate |
8mm 10mm Thickness Steel Plates Astm A36 Standards Size 6000 mm x 2000 mm
Specifications | ASTM / ASME |
Standard | EN 10025-2: 2004 Hot rolled products of structural steels. Technical delivery conditions for non-alloy structural steels |
Specialize | Shim Sheet, Perforated Sheet, B. Q. Profile. |
Size | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Equivalent Grade of ASTM A36 Carbon Steel Plates
USA | Germany DIN,WNr | Japan JIS | France AFNOR | England BS | Canada HG | European old EN | Belgium NBN | Spain UNE |
1015 A283C SSGr.33 | RSt37-2 St37-2 | SM400A SS400 | E24-2 | 40A 40B | 230G | Fe360B Fe360BFN S235JRG2 | AE235B | AE235B-FN |
A283D A529 Gr.D | RSt42-2 St 44-2 | SS400 | E28-2 | 161-430 43A 43B | 260W 260WT | Fe430B | AE295B | AE255B |
C | Mn | P | S | Si | Co | CEV |
max 0.27 | max 1.20 | max 0.04 | max 0.05 | 0.15 – 0.40 | max 0.20 | – |
Yield Point ksi, min | Tensile Strength ksi | % Elong. 2” Bend |
36 | 58-80 | 23 |
![]() |
