Alloy 625 Wn Bl Duplex Stainless Steel Flanges 5000psi 10000psi 15000psi Api 6a Type 6b 6bx Astm B564

Categories Duplex Stainless Steel Flanges
Brand Name: HT
Model Number: 5000PSI 10000PSI 15000PSI API 6A TYPE6B 6BX ASTM B564 Alloy 625 WN BL flange
Certification: ISO9001
Place of Origin: China
MOQ: 1 pcs
Price: Negotiation
Payment Terms: L/C,T/T, Western Union
Supply Ability: 1000 pcs per month
Delivery Time: 30-35 working days
Packaging Details: wooden case, wooden pallet
Product Type: Flange, Disc, Foring, Shaft Sleeves
Name: 5000PSI 10000PSI 15000PSI API 6A TYPE6B 6BX ASTM B564 Alloy 625 WN BL flange
Size: 1/2"-24" DN10-DN1000
Class: 150#-2500#, PN6-PN100
Surface: oil rusted, yellow
Material: Nickel alloy/stainless steel/duplex stainless
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Alloy 625 Wn Bl Duplex Stainless Steel Flanges 5000psi 10000psi 15000psi Api 6a Type 6b 6bx Astm B564

5000PSI 10000PSI 15000PSI API 6A TYPE6B 6BX ASTM B564 Alloy 625 WN BL flange


1. Inconel 625 WN SO SW BL flange useful information


ComponentWt. %
AlMax 0.4
CMax 0.1
CoMax 1
Cr20 – 23
FeMax 5
MnMax 0.5
Mo8 – 10
Nb3.15 – 4.15
NiMin 58
PMax 0.015
SMax 0.015
SiMax 0.5
TiMax 0.4

Physical PropertiesMetricEnglishComments
Density8.44 g/cc0.305 lb/in³




Mechanical Properties
Tensile Strength, Ultimate880 MPa128000 psiAnnealed. Value at room temperature. Value at 650°C is 760 MPa.
Tensile Strength, Yield460 MPa66700 psiAnnealed. Value at room temperature; 0.2% offset. Value at 650°C is 290 MPa.
Elongation at Break50 %50 %Annealed. Value at room temperature. Value at 650°C is 55%.
Electrical Properties
Electrical Resistivity0.000129 ohm-cm0.000129 ohm-cm
Magnetic Permeability1.00061.0006at 200 oersted (15.9 kA/m)
Curie TemperatureMax -196 °CMax -321 °F

2. ASTM B564 Alloy 625 description

Flange FacingFlat face FF, raised face RF, Ring type joint RTJ
Design:ASMI B16.5, ASME B16.47 Series A ( MSS SP 44), Series B (API 605)
Working Pressure:Class 150, 300,400, 600, 900, 1500, 2500.
Size:1/2’-24’
Material ClassGroup 3.1-3.19
Alloy Material to make BarNi-Cr-Fe alloy: alloy 020
Ni-Cr alloy: alloy 718, X-750, 80A.
Ni-Cr-Mo alloy: alloy 625, 686, C-22, C-2000, G-30, G-35.
Ni-Fe-Cr alloy: alloy 925.
Ni-Mo alloy: alloy B-2, B-3.
Ni-Mo-Cr alloy: alloy C-276.
Industry served:

Oil and gas, Chemical and petrochemical, Power generation, Marine, Aerospace, Defence.


3. Alloy 625 nickel alloy flange tests we do:

1. Raw material test

2. PMI test

3. Dimension test

4. Visual test

5. Penetrant test

6. Ultrasonic test

7. IGC test and so on.
