Corrugated Incline Conveyor Belt Adjustable Speed 0-90 Degree Angel Customized Size

Categories	Enclosed Belt Conveyor
Brand Name:	JINRUI
Model Number:	FDJ
Certification:	ISO/CE
Place of Origin:	CHINA
MOQ:	1 SET
Price:	negotiate
Payment Terms:	L/C, T/T
Supply Ability:	10set per month
Delivery Time:	10-15 working days
Packaging Details:	Seaworthy packing
Frame Material:	Carbon steel
Belt wideth:	B500/650/800/1000/1200/1400MM
Voltage:	220v/380v/415v/440v
Dimension:	B 500/650/800/1000/1200mm
Color:	Customized size
Belt material:	PU/RUBBER

Contact Now

Add to Cart

Company Info.

Xinxiang jinrui machinery factory

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Corrugated Incline Conveyor Belt Adjustable Speed 0-90 Degree Angel Customized Size

Introduction

Adjustable Speed Protection Corrugated Compost Enclosed Belt Conveyor For Mining ore are raised edge and large dip angle belt conveyor introduce belt with wavy raised edge and cross cleats,The machine is mainly used for conveying bulk materials in large inclination angle. The inclination angle can reach from 0° to 90°(the best angle is below 70°).

Advantages and Features

1. Low maintenance cost.
2. Large transport capacity, and it can avoid material spilling effetely.
3. The belt can facilitate switching from horizontal to inclined conveying and from inclined to horizontal conveying.
4. It saves a lot space as it allows material conveying at 0-90 degree.
5. The sidewall belt conveyor is widely used in coal, food, building, chemical, water and electricity and metallurgy industry.

Tech data

Belt width	Flange high	Diaphragm spacing	Angle of inclination
			30°		40°		50°		60°		70°		90°
mm	mm	mm	Delivery value(m3/h) speed of belt=1m/s
	80	126	39	31		25		20		17		10
500	120	252	52	40		32		26		21		-
	160	378	65	52		42		34		28		17
	80	126	59	47		37		31		25		15
650	120	252	78	60		48		39		32		-
	160	252	105	85		68		55		45		28
	120	129	99	76		60		49		40		-
800	160	252	136	110		88		72		58		36
	200	378	148	114		91		74		61		37
	160	252	223	180		144		117		96		59
1200	200	378	250	193		154		126		103		63
	240	378	342	280		224		183		149		91
	300	504	410	352		290		237		198		118
	200	252	299	231		185		151		123		75
1400	240	378	422	345		276		225		184		113
	300	348	512	440		363		296		241		148

Selection Conditions

♦ Material to be processed: _____	♦ Max. granule size of the feeding material: _____mm
♦ Handling capacity (Ps. It means the total	♦ Percentage of Max. granule in material:_________%
material capacity feeding from the inlet): _____t/h	♦ Upstream equipment (Ps. It means what kind of
♦ Bulk Density: _____t/m3	equipment is used to feed the material): _____
♦ Material temperature: _____ºC;	♦ Downstream equipment (Ps. It means what kind of
♦ Water content:____%	equipment is used to discharge the material): _____
♦ Material is corrosive or not: ____ (Ps. Yes or No)	♦ Working power supply: _____V ______HZ
♦ Material is sticky or not: ____ (Ps. Yes or No)	♦ Please refer to the following picture and provide the
♦ Working environment is indoor or outdoor	relevant parameters:L1____m, L2___m, H___m, α____°
or indoor and outdoor: ______________	Working environment temperature: ______ ºC
