Aquafeed Animal Feed Automated Batching Systems For 10KG To 50KG Into Bags Bottles Barrels

Aquafeed Animal Feed Batching Equipment For 10KG To 50KG Into Bags Bottles Barrels

Product Description:

Automatic Batch Weighing Systems encompasses a range of batch weighing systems, with varying degrees of automation incorporated in them. The systems can be put to use in almost any kind of material where batches are made on weight. These systems are highly flexible in that it can be designed for low weights, high accuracy batches as well as high weights, low accuracy batches.

Aquafeed batching equipment is key in aquafeed mixing process. It is a aquafeed mixer pro-portioner. For your mixed aquafeed manufacturing, there are accurate batching machines for aquafeed for you to choose. Whether you want static or dynamic, mini batching device or machine with large batch hopper, we can meet your needs. What’s more, it is also available to make them into mobile batching machines.

Technical Specification:

What Are The Structures Of our Batching System For Batching Accurately?

Weighing system: The weighing device consists of feeder controller, weighing sensor, adjusting sensor, weighing frame. It weighs the materials with high accuracy.

Feeding system: There are conveyor support, auger screw or skirt ring belt, motor, reducer, frequency converter for forming the feeding system. When the weighing finishes, it will stop feeding automatically.

Control system: This system mainly controls the weighing and feeding system. You can set your value by this control system. It mainly includes inverter control cabinet, instrument control cabinet.

Amazing Aquafeed Batching Machine Functions make You Mix. Aquafeed Easily:
Batching system plays an important role for you to produce mixed aquafeed. our batching machine manufacturer produces batching equipment for improving your user experience.
1. It can calculate the feeding speed. There are quick feeding and slow feeding for you to choose.
2. Our batching equipment can memory the formula you have set. Once you want to apply the formula, it is convenient for you to recall it.
3. This batching machine can be customized for your different requirements. You can choose different specifications of machines for your requirements.
4. It manages your formula well. You can input, memory, recompose and delete the formula easily.
5. There is alarm function for controlling your materials feeding well.
6. It is alternative for you to choose the feeding methods. If you choose the screw auger or belt feeding, it can test the digital divide automatically and manually. While, as for the feeding by valve, you should modify digital divide by slow feeding.

The C-Series Systems are designed to cater to following needs:
1. Number of Ingredients: 3 to 15 nos.
2. Maximum storage capacity for each ingredient: 10 kg.
3. Batch time range: 1 min to 4 minutes.
4. Maximum number of batches: About 500 batches/8 hours.
5. Suitable for Weighing: 20 grams to 5 kg of each ingredient.
6. Accuracy range: 5 grams or 1% of total weight required whichever is higher.

Equipment photos:
