Austenitic Seamless Stainless Steel ASTM A213 904L N08904 1.4539 pipe tube

ASTM A213/ASME SA213 covers low alloy steel pipes and minimum-wall-thickness, seamless ferritic and austenitic steel, boiler and super-heater tubes and austenitic steel heat-exchanger tubes, designated Grades TP304,TP304H,TP304L,TP310S, TP310HCbN, TP316, TP316H, TP316L etc.

Grades TP304H, TP309H, TP309HCb, TP310H, TP310HCb, TP310HCbN, TP316H, TP321H, TP347H, TP347HFG (fine grained) and TP348H are modifications of Grades TP304, TP309S, TP309Cb, TP310S, TP310Cb, TP316, TP321, TP347, and TP348, and are intended for high-temperature service, such as for superheaters and reheaters.

For ASTM A213 Seamless Tubes with diameters less than 1/8 in. [3.2 mm] in inside diameter or 0.015 in. [0.4 mm] in thickness,mechanical property requirements won’t apply. Tube with other dimensions may be furnished comply with other requirements.

904L Stainless Steel Tube | UNS N08904 | WNR 1.4539

UNS NO8904, commonly known as 904L, is a low carbon high alloy austenitic stainless steel which is widely used in applications where the corrosion properties of AISI 316L and AISI 317L are not adequate.

The addition of copper to this grade gives it corrosion resistant properties superior to the conventional chrome nickel stainless steels, in particular to sulphuric, phosphoric and acetic acids. However, there is limited use with hydrochloric acids. It also has a high resistance to pitting in chloride solutions, a high resistance to both crevice and stress corrosion cracking. Alloy 904L performs better than other austenitic stainless steels due to the higher alloying of nickel and molybdenum.

The grade is non-magnetic in all conditions and has excellent formability and weldability. The austenitic structure also gives this grade excellent toughness, even down to cryogenic temperatures.

The high chromium content promotes and maintains a passive film which protects the material in many corrosive environments.904L has a greater resistance to precipitation of ferrite and sigma phases on cooling and welding than other stainless steels containing molybdenum such as 316L and 317L. There is no risk of intercrystalline corrosion on cooling or welding due to the low carbon content. Its maximum service temperature is at 450°C.

This grade is particularly useful in control and instrumentation tubing applications where 316 and 317L are not suitable.

SS 904L Pipe Size Range and Specifications

Physical Properties (Room Temperature)

Chemical Composition (% by weight)

Huitong Group was established in 1978. After 38 years'development and innovation,by now,Huitong Group has set up multiple subsidiary companies.Among them,Zhengzhou Huitong Pipe Fitting Co.,Ltd.,with the indepent right of import and export, is mainly engaged in exporting steel pipe and pipe fittings for Huitong Group and assisting another subsidiary company of Huitong Group:Zhengzhou Huitong Machanical Equipment Co.,Ltd., in exporting machanical equipment.

Zhengzhou Huitong Pipeline Equipment Co.,Ltd.,with the strong support of Huitong Group,and years'development and innovation, are more and more professional in technical service and can manufacure products with all kinds of material,shape and size. Especially in elbows, tee, reducer, flange and pipe cap etc., we have gained more than 20 product patent, and hundreds of technology patent. Also,we have gradually taken an ireplacable role in High-pressure,high-temperature and anti-corrosion area. With the continuous construction of engery in China,such as petrol gas,electric power,etc.,our company has become the purchasing center of whole set fittings for such projects.In 2009,a foreign trade team established,is manily engaged in oil gas and electric power projects abroad.By now, our products have been exported to

Canada,Malaysia,Parkistan,UAE, Eygpt,the Middle East countries, etc.. We have passed the qualification of ISO9001:2000 and API quality certification system. High-quality products and high-class service are well received by abroad customers in this industry. The unique diversified production line can offer you one-package serive, you can pruchase all complex products from us at one time. What's more, our sufficient material stock and conventional product stock can ensure you receive satisfied product in the shortest time.

With powerful financial strength,advanced managerial concept, excellent marketing service,strict quality control system and integrated marketing team,we would like to develop together with you hand in hand. Adhering to the operation principle of "faith first and clients foremost", we always supply high quality products, complete after-sales service and favorable prices. We sincerely hope to establish long-term cooperation with you on the basis of mutual benefits, reciprocity and common development.

People who interested in our products or want to get more information about us,contact us,please!Looking forward for your inquiry.
