Categories | Automatic Welding Machine |
---|---|
Brand Name: | JINHUA |
Model Number: | JH-WR400 |
Place of Origin: | WUXI, CHINA |
MOQ: | 1 Unit |
Price: | USD+2000-50000+Unit |
Payment Terms: | T/T |
Supply Ability: | 30+Unit+Per Month |
Delivery Time: | 15-60 days |
Packaging Details: | Wooden Box Package |
Machine Type: | Ring seam welding machine |
Applicable Industries: | Manufacturing Plant |
Dimensions: | 5000*1500*2600 |
Usage: | Ring seam welding |
Certification: | ISO900 |
Warranty: | 1 YEAR |
After-sales Service Provided: | Video technical support, Online support |
Application: | Automatic welding of end caps of heavy hydraulic cylinders |
Special Machine For Girth Seam Welding External Cylinder Seam Welding Machine For Hydraulic Cylinder
I. Machine Instruction
JH-WR400 is mainly used for the automatic welding of end caps, flanges, lifting lugs and piston rods of heavy-duty hydraulic cylinders. The welding process can be completed by butt welding the cylinder end cover and the hydraulic cylinder flange once.
2. Supply Ability
1 Set per Month
3. Packaging Details
The external cylinder seam welding machine of the hydraulic cylinder tube is exported and packaged in a wooden box, and the body is covered with a transparent plastic film.
Condition: | New | Wall thickness range: | 10mm ~ 35mm |
Place of Origin: | WuXi, China (Mainland) | Oil pressure adjustment range: | 0.5-5MPa. |
Inner diameter range: | φ101.6mm~φ290mm | Dimensions: | Customized |
Outer diameter range: | 120mm ~ 450mm | Weight: | Customized |
![]() |
