1 / 8 Folding 400mm 2000 Sheets / Min Napkin Manufacturing Machine

1 / 8 Folding Dinner Paper Napkin Machine 400mm , Napkin Manufacturing Machine

Description

Eight Fold Dinner Napkin Machine 2000 Sheets Per Min Four Deck 400mm size is kind of machine to produce the napkin paper. Napkin paper unfolded size can be from 170x170mm to 400x400mm according to your need, each model has the same style and productive technology. It possesses reasonable design, stable function, high production output, simple operation and easy maintaining. In addition, it is suitable for various kinds of factory’s productive investment.

Main production process: Jumbo roll tension unwinding—calender press (as your request) —color printing (as your request)—embossing—longitudinal folding—paper feeding—transverse folding—slitting.)

The machine have auto counting unit, the number of the pieces of paper can be decided by you. The machine can be equipped with 1-8 colors printing unit, according to your requests. (The number of the colors different and machinestructure may be different partly)

Specification

Specification of Raw Material

1) Diameter 1200mm

2) Width 540-1500mm

3) Thickness :13-20g/m2(2 layers )23-25g/m2(1 layer)

4) Inner diameter of core:76mm

Specification of Finished Product

1) Unfolding size:180-500x180-500±2mm(LxW)

2) Folding size:90-250x90-250±2mm(LxW)1/4 folding

Equipment Disposition

1) Pneumatic lifter

2) One paper return stand

3) Flat belt (controlled by cylinder)

4) Hand-wheel adjust the tension of unreel.

5) Vertical slitting unit

6) Steel roller against wool roller

7) 3 sets of folding plate

8) Band saw slitting

9) Knife-sharping unit

10) Individual Electrical Cabinet

11) Main motor 5.5kw Frequency-converting (380V50HZ) Cutting paper power 2.2KW

Machine Shipping and Packing

1. We use three-ply board pack the machines into standard export wooden case.

2. We will provide you the Fumigation Certificate for free.

3. We Sincerely invite you to visit our factory to inspect the machines before we shipping.

4. Before shipping, we will spend more 2 weeks to test the machines with raw materials to double ensure the machines running stready
