OM4 OFNR Jacket Fiber Optic Patch Cord With MTRJ - LC Connector LAN / CATV

Categories Fiber Optic Patch Cord
Brand Name: Fujioptics/OEM/ODM
Model Number: FJ-SC0133
Certification: ROHS.CE ,ISO9001
Place of Origin: CHINA
MOQ: 100pcs
Price: Negotiation
Payment Terms: L/C, D/P, Western Union
Supply Ability: 10000pcs
Delivery Time: 5-7 working days
Packaging Details: PE bag ,Carton box
Connector Type: MTRJ
Ferrule End-face: UPC
Fiber Type: OM4 50/125um
Cable Type: Duplex
Cable OD: 2.0mm
Cable Jacket: LSZH Outer Jacket
Cable Length: 1M, 2M, 3M Or Customized
Cable Color: Aqua, Purple, Violet Or Customized
High Light: fiber optic jumper, fiber optic cable patch cord
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

OM4 OFNR Jacket Fiber Optic Patch Cord With MTRJ - LC Connector LAN / CATV

OM4 OFNR Jacket Optical Cord with MTRJ - LC Connector LAN / CATV

Description:


Fiber Patch Cords are a length of optical fiber with two ends adding connectors to connect beam path. Fiber Pigtail is a length of fiber permanently attached connector only at one end.
Optical patch cords assembled with various types of connectors (such as FC, SC, ST, LC, MU, MTRJ etc.) There are three kinds of polishing fiber end-face: PC, UPC and APC .

Features:
High return loss
Low insertion loss
OFNR, OFNP, LZSH or PVC jacket
CCTC A Type optical fiber Ferrule
Fan-out available (Ribbon type / bundle type)
Customized Lengths Upon Request

Hybrid patch cords are available upon request

Application:
LAN/CATV
Building Cabling
Network, Broadband
Telecommunication
Communication equipment rooms, FTTX
Optical appliances connection


Specification:

Multimode Fiber Optic Patch Cord
Fiber type

OM1(62.5/125μm) ; OM2(50/125μm) ;

OM3/(50/125μm-150; 50/125μm-300);

OM4 (50/125μm-550)

Operating Wavelength850 nm
Jacket materialPVC/LSZH/OFNP/OFNR
Diameter of fiber0.9/1.6/2.0/2.8/3.0mm
ContectorSC LC ST FC MT MTRJ MPO or customized
polishing methodPCUPCAPC
Insertion loss (IL)≤0.2dB≤0.2≤0.3
Return loss (RL)≥45dB≥50dB≥60dB
Repetitiveness≤0.1dB
Exchangeability≤0.2
Durability>1000 times
Operating Temperature(ºC)-40~85
Storage Temperature(ºC)-40~85
lengthcustomized


Order Information:

Fiber Optic Patch Cord
Connector TypeCeramic Ferrule
End Face

Cable Diameter

(mm)

Simplex/DuplexSingle mode
/Multi-mode

Length

(meter)

FCPC/UPC/APCΦ0.9, Φ2,Φ3Simplex/DuplexSM/MMCustomized
SCPC/UPC/APCΦ0.9, Φ2,Φ3Simplex/DuplexSM/MMCustomized
STPC/UPCΦ0.9, Φ2,Φ3Simplex/DuplexSM/MMCustomized
LCPC/UPCΦ0.9, Φ2Simplex/DuplexSM/MMCustomized
MUPC/UPCΦ0.9, Φ2Simplex/DuplexSM/MMCustomized
MTRJPC/UPCΦ0.9, Φ2DuplexSM/MMCustomized


Product Picture:
OM4 OFNR Jacket Fiber Optic Patch Cord with MTRJ - LC Connector LAN / CATV 0

Cheap OM4 OFNR Jacket Fiber Optic Patch Cord With MTRJ - LC Connector LAN / CATV for sale
