Dia 1.2m 1.5m 1.8m 6 Layers Inflatable Airbag Roller For Ship Launching

Categories Ship Launching Airbags
Brand Name: JUVI
Place of Origin: Chongqing of China
MOQ: 1
Price: negotiable
Payment Terms: Western Union, MoneyGram, D/P, D/A, L/C, T/T
Delivery Time: in stock
Name: ship airbag
Application: ship marine boat vessel yacht
Certificate:: CCS / SGS / BV / ISO9001 etc.
Working Pressure:: 0.05MPa to 0.15Pa
type 1: 6-8 layer
Lifespan:: 8~10 Years
MOQ: 1 pc
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Dia 1.2m 1.5m 1.8m 6 Layers Inflatable Airbag Roller For Ship Launching

Inflatable Airbag Rollers For Ship Launching Cover Ball Valve Repair Kit


Specification


Airbag Layer and Pressure:
D=0.8mD=1.0mD=1.2mD=1.5mD=1.8mD=2.0m
3 layers0.13MPA0.10MPA0.09MPA0.07MPA0.06MPA0.05MPA
4 layers0.17MPA0.13MPA0.11MPA0.09MPA0.08MPA0.07MPA
5 layers0.21MPA0.17MPA0.14MPA0.11MPA0.09MPA0.08MPA
6 layers0.25MPA0.20MPA0.17MPA0.13MPA0.11MPA0.10MPA
7 layers0.29MPA0.23MPA0.20MPA0.15MPA0.13MPA0.12MPA
8 layers0.33MPA0.26MPA0.23MPA0.17MPA0.15MPA0.14MPA


Airbag storage


When the airbag is not used for a long time, it should be washed and dried, filled with talcum powder on the outside, and placed in a dry, cool and ventilated place indoors. The airbag should be stretched out and placed flat, not stacked, and no heavy objects should be stacked on the airbag.


The place where the air bag is stored should be far away from heat sources.


The airbag should not be in contact with acids, alkalis, grease and organic solvents.


Airbag packaging and transportation


According to the People’s Republic of China Shipping Industry Standard CB/T 3795-1996, the packaging, transportation and storage of marine airbags should follow the following standards:


  1, packaging

After folding, it is bundled and packed with a plastic woven bag.

  2, transportation

When the airbag is transported in a short distance, it should be hoisted, lifted, and rolled in an inflated state. Towing on the ground is strictly prohibited.


Airbags should be folded and fixed on a pallet during long-distance transportation, with cushions underneath and wrapping with stretch film on the outside.


marine ship launching airbag
Diameter (D):From 0.3m to 2.8m
Effective Length (EL):From 5.0m to 24m
Standard Number of Layers:Usually 4-11 layers
Loading Capacity:About 10-40 T/M
Max. Loading capacity Per Unit30-1000 Ton/Unit


Company Introduction


Chongqing Juvi Marine Machinery Company is an integrated marine technology company that presently specializes in productdesign,production, and sales.Juvi company is administered by the marine equipment production systems. Every factory that our partner with has passed theCCS,ABS,DNV,LR,NK,RINA,ISO9002, TS16949, UL and other related systems authentication.


More than 10 years of accumulated experience, high-quality products, coupled with our philosophy of absolute integrity in all business dealings have earned us unanimous praise from old and new clients alike, as well as a distinctive reputation in the industry.


Main Products


1. Marine ship yacht boat light: Navigation signal light, Incandescent light, Fluorescent light, Searchlight/ Spot Light/ Flood Light, Explosion-proof light etc.
2. Marine deck: Winch, Windlass, Capstan (AC, DC, Vertical, Horizontal, Electric, Hydraulic etc.)
3. Marine deck mooring: Anchor, Anchor chain.
4. Marine life-saving: Rescue boat, Life Jacket, Buoy etc.
5. Customized products:according to customers' request.
