light weight : The dry weight of AAC block is 400-700kg / m³, which
is only 28% of clay
brick , and 20% of concrete block, reducing the weight of the
building.
| Sign In | Join Free | My ecer.jp |
|
| Sign In | Join Free | My ecer.jp |
|
| Categories | AAC Production Line |
|---|---|
| Place of Origin: | Henan, China |
| Brand Name: | zhongke |
| Certification: | ISO9001:2008, BV,CE.CQC |
| Supply Ability: | 35 Set/Sets per Month |
| Packaging Details: | standard package Container, spare parts in wooden case, bulk goods in plastic cloth |
| MOQ: | 1.0 Set/Sets |
| Price: | $60,000.00 - $1,000,000.00 / Set |
| Applicable Industries: | Manufacturing Plant, Construction works , Energy & Mining |
| After Warranty Service: | Video technical support, Online support, Field maintenance and repair service |
| Local Service Location: | None |
| Showroom Location: | None |
| Condition: | New |
| Type: | AAC block |
| Brick Raw Material: | flyash or sand |
| Processing: | Brick Cutting Machine |
| Method: | grinding-dosing-precuring-cutting-autoclaving |
| Automatic: | Yes |
| Max. Capacity: | 20000M3/year |
| Voltage: | AC 380v, three phases |
| Dimension(L*W*H): | according to its situation |
| Key Selling Points: | Easy to Operate |
| Brick size: | 600x400x200mm |
| Machinery Test Report: | Provided |
| Video outgoing-inspection: | Provided |
| Marketing Type: | New Product 2020 |
| Warranty of core components: | More than 5 Years |
| Core Components: | Gear, Motor, Bearing |
| Feature: | Manower saving, High automation |
| Raw material: | Cement, Lime, Sand(Fly ash), Gypsum, Aluminum powder, Water |
| Autoclave length: | different size available |
| Warranty: | One year, One year |
| Cutting machine: | air turning / ground turning optional |
| Customized design: | available(different block size, density) |
| Supplier certificate: | ISO9001:2008, BV |
| Pre-sale service: | Plant layout, production line design |
| Free training: | QC manager & equipment maintenance technician |
| Port: | Qingdao or Tianjin port |
Introduction of AAC Block Production Line:
1. Storing and supplying of raw materials of AAC blocks:
All raw materials are carried into factory by trucks, such as Fly
ash, sand or lime are gathered in specified raw materials field
waiting for use. Sacks of cement and bulk cements stored in cement
warehouse. Chemicals and aluminium powder are separately keeped in
chemical warehouse and aluminium ware hours.When used, these raw
materials are carried into workshop respectively.
2. Processing of raw materials:
Fly ash, sand or limestone is sent into ball mills by vibration
feeders and belt conveyor.Then fine powders of flyash,sand or lime
are pumped into slurry tank.
Quick lime is sent by vibrating feeder and belt conveyor into jaw
crushers to smash. Smashed lime is sent into lime silo by bucket
elevator and then is transported into ball mills by screw conveyor.
Fined materials are sent into proportion bin by screw conveyor and
bucket elevator.
3. Aerated block ingredients,stiring and casting
Flyash (or sand or stone powder )and waste slurrry are measured in
measuring tank.After the measuring and mould in their place,slurry
stirring begins. Slurry temperature should reach about 40°c.
4. Aerated block’s procuring and cutting.
Autoclave
|
