GMP Standard Rotary Tablet Press Machine

Categories Tablet Press Machine
Brand Name: SED Pharma
Model Number: SED-445-23Y-D
Certification: CE
Place of Origin: China
Payment Terms: T/T,L/C, MoneyGram,Cash
MOQ: 1 Set
Price: Negotiable
Supply Ability: 30 Sets per month
Delivery Time: 50-60 Days after receiving the deposit
Packaging Details: Wooden Case
Name: GMP Standard Rotary Tablet Press Machine
Station: 23 stations
Capacity: 20700 tablets per hour
Power: 7.5 kw
Voltage: 220V 50HZ
Weight: 3200kg
material: stainless steel
key word: Tablet Press Machine
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

GMP Standard Rotary Tablet Press Machine

GMP Standard Rotary Tablet Press Machine


Product Description of Tableting Machine​


The machine is used for pressing various granular raw materials into round and irregular shapes. It is a basic equipment suitable for mass production.


The turret speed, material filling depth and the tablet thickness all can be adjusted when pressing. The mechanical buffer device on the machine can avoid the damage of parts caused by overload.


The machine can be equipped with a powder suction box. The dust generated during the operation of the machine can be absorbed through the suction nozzle to avoid sticking and clogging, and the raw materials can be recycled and reused.


Product Parameters of Tablet Making Machine

ITEMspec
Type SED-445-23Y-D
Station23 stations
Power7.5 kw
Voltage380v 50HZ (according to the request of the customer)
Max pressure100KN
Max diameter of tablets40mm
Max filling depth33mm
Max thickness of tablet16mm
Table valid diameter445mm
Speed6-- 15 RPM
Max capacity20700 tablet
Working table diameter445mm
Outer diameter of the punch45mm
Height of middle die38mm
Diameter of upper and lower punch45mm
Length of upper punch175mm
Length of lower punch180mm
Dimension1000x1250x1900mm
Weight of machine3200kg


Feature of Tablet Punching Machine


1. The material of the machine is made of stainless steel with totally closed, the surface of turntable deal with polished and prevent cross pollution which meet the GMP standard.


2. It is equipped with Organic-glass perspective window for tablet producing observation. Each perspective window could be fully opened and easy for cleaning and maintenance.


3. It is adopts the import Frequency Timing with Electromagnetism Clutch.


4. The system of Hydraulic Pressure keep the working pressure under steady, when the pressure over-loading, it will be stopped the machine automatically.


5. Driving system is equipped with oil box and running under oil, easy for heat dissipation and wear-resistance.


6. It is equipped with Dust Collector as well, which avoid the dust emission, and recycle to save dust


Application of Tablet Punching Machine
