| Categories | Stainless Steel Seamless Pipe |
|---|---|
| Brand Name: | CHENGYU |
| Certification: | ISO |
| Place of Origin: | CHINA |
| MOQ: | 50KG |
| Price: | 2.0-8.0USD/KG |
| Payment Terms: | Western Union |
| Supply Ability: | 10000TONS |
| Delivery Time: | 15-30DAYS |
| Packaging Details: | WOVEN BAGS,PLYWOOD PACKAGE |
| Model Number: | 630x20 |
| Steel grade: | 300 Series |
| Application: | Construction,boiler,oil and gas,electric |
| Standard: | ASTM,AISI,GB,DIN,JIS |
| Product name: | Stainless Steel Pipe,304 304L 316 316L 321 310S Stainless Steel Welded / Seamless Tube,Factory Direct Sales Stainless Steel Pipe For Electric Heating Element,Seamless stainless Steel pipe/tube |
| Grade: | 304 |
| Company Info. |
| wenzhoushi chengyu steel co.,ltd |
| View Contact Details |
| Product List |
Quick Details
Standard:JIS,AISI,ASTM,GB,DIN,EN,GOST
Type:Seamless
Grade:201/304/304L/304LN/304H/316Ti/316L/316H/321/321H/904L/310S/347 etc
Big Outdiameter Size:OD273mm-1024mm WT5mm-68mm LENGTH 50mM-12000mm
Application:Petroleum,Chemical Engineering,Fluid Machinery,Irrigation Works,Electric Power,Environmental,Etc
Surface Finish:Brush polish,Hairline,160grit,Mirror,Bright,Etc
Technique:Cold rolling,Cold drawing
Test: Hardness Test,Hydrostatic Test,Ultrasonic Test,Eddy Current Test,Dimensional Checking,Chemical Analysis Etc
Inspection:100%
Price Term:FOB,CFR,CIF or as negotiation
Knowledge:304 large diameter stainless steel Pipe in the air or chemical corrosion medium can resist corrosion or a Kind of high alloy
steel.304 stainless steel pipe is a beautiful surface and good corrosion resistance,without plating color and other surface treatment,and Play
the Inherent surface performance of stainless steel,used in a variety Of steel.Usually called stainless steel.Represents the performance of 13
Chromium Steel .18-8 chromium nickel steel and other high alloy steel.From the perspective of metallography analysis, because the stainless
steel contains chromium and the surface of the formation of a very thin chromium film, the film separated from the invasion of oxygen in the
steel plays a role in corrosion resistance.In order to maintain the inherent corrosion resistance of stainless steel, the steel must contain more
than 12% chromium.304 is a kind of universal stainless steel, which is widely used in the production of equipment and parts requiring good
comprehensive properties (corrosion resistance and formability).304 stainless steel is a grade of stainless steel produced according to
American ASTM standard.304 is equivalent to China's 0Cr19Ni9 (0Cr18Ni9) stainless steel.304 contains 19% chromium and 9% nickel.304 is
the most widely used stainless steel and heat resistant steel.
| ASTM Chemical Composition (%,max) | |||||||||
| Grade | C ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Ni ≤ | Cr ≤ | Mo | Others |
| 304 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 8.00-11.00 | 18.00-20.00 | ||
| 304H | 0.04-0.1 | 0.75 | 2 | 0.04 | 0.03 | 8.00-11.00 | 18.00-20.00 | ||
| 304L | 0.035 | 0.75 | 2 | 0.04 | 0.03 | 8.00-13.00 | 18.00-20.00 | ||
| 304N | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 8.00-11.00 | 18.00-20.00 | N:0.1-0.16 | |
| 304LN | 0.035 | 0.75 | 2 | 0.04 | 0.03 | 8.00-11.00 | 18.00-20.00 | N:0.1-0.16 | |
| 309 | 0.15 | 0.75 | 2 | 0.04 | 0.03 | 12.00-15.00 | 22.00-24.00 | ||
| 310 | 0.15 | 0.75 | 2 | 0.04 | 0.03 | 19.00-22.00 | 24.00-26.00 | ||
| 316 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 11.00-14.00 | 16.00-18.00 | 2.00-3.00 | |
| 316H | 0.04-0.1 | 0.75 | 2 | 0.04 | 0.03 | 11.00-14.00 | 16.00-18.00 | 2.00-3.00 | |
| 316L | 0.035 | 0.75 | 2 | 0.04 | 0.03 | 10.00-15.00 | 16.00-18.00 | 2.00-3.00 | |
| 316N | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 11.00-14.00 | 16.00-18.00 | 2.00-3.00 | N:0.1-0.16 |
| 316LN | 0.035 | 0.75 | 2 | 0.04 | 0.03 | 10.00-15.00 | 16.00-18.00 | 2.00-3.00 | N:0.1-0.16 |
| 317 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 11.00-14.00 | 18.00-20.00 | 3.00-4.00 | |
| 321 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 9.00-13.00 | 17.00-20.00 | Ti:5xC%-0.70B | |
| 321H | 0.04-0.1 | 0.75 | 2 | 0.04 | 0.03 | 9.00-13.00 | 17.00-20.00 | Ti:4xC%-0.6 | |
| 347 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 9.00-13.00 | 17.00-20.00 | Nb+Ta:10xC%-1.00 | |
| 347H | 0.04-0.1 | 0.75 | 2 | 0.04 | 0.03 | 9.00-13.00 | 17.00-20.00 | Nb+Ta:8xC%-1.00 | |
| 329 | 0.089 | 0.75 | 2 | 0.04 | 0.03 | 2.50-5.00 | 23.00-28.00 | 1.00-2.00 | |
| 316Ti | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 11.00-14.00 | 16.00-18.00 | 2.00-3.00 | Ti:5xC%-0.75 |
| S31803 | 0.03 | 1.00 | 2 | 0.03 | 0.02 | 4.5-6.5 | 21.00-23.00 | 2.50-3.50 | N:0.08-0.3 |
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
20 feet container load 25tons pipes whose length is under 5.8m
40 feet container load 28tons pipes whose length is under 11.8m
|
