UN38.3 Battery And Package Testing Meet IEC 1-2500Hz Vibration Test Systems

Categories Sine Vibration Testing
Brand Name: ASLI
Model Number: ES-6
Certification: CE
Place of Origin: Guangdong, China
MOQ: 1 Set
Price: 40000 dollars per month
Payment Terms: T/T
Supply Ability: 30 Sets per Month
Delivery Time: 40 working days
Packaging Details: Standard Export Poly Wood Case
Customized support: OEM
Brand: ASLI
Power: Electronic
Certificate: ISO 9001:2008
Packing Material: Poly wood case
Vibration: 3 Axis
Vibration Force: Customized
Table Size: Customized
Max Load: 300
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

UN38.3 Battery And Package Testing Meet IEC 1-2500Hz Vibration Test Systems

UN38.3 Battery And Package Testing Meet IEC 1-2500Hz Vibration Test Systems


TECHNICAL PARAMETERS OF UN38.3 Battery And Package Testing Meet IEC 1-2500Hz Vibration Test Systems


ItemDescription

Force

(Maximum)

Sine600Kg.f peak
Random600Kg.f r.ms
Shock600Kg.f peak
Frequency Range5~2500 Hz
Max. Displacement(Peak to Peak) 51mm
Max. Velocity1.8m/s
Max. Acceleration100G (980 m/s2) without loading
Vibration directionVertical and horizontal
Armature Diameter200 mm
Effective Armature Mass6kg
Table screw17×M10
Max. payload300kg
Magnetic Leakage<10gauss
Axial Vibration Isolation Frequency2.5HZ
Allowable eccentric moment>300N.m
Dimension1200mm*790mm*840mm (Head Expander is excluded)
Weight1600kg (Slip Table is excluded)
Power supplyAC 3-phase 380V/50Hz,18 KVA
Grounding resistance≤4Ω
Air compressor0.4-0.6Mpa (provided by customer)
Cooling methodAir cooling

PRODUCT DESCRIPTION


UN38.3 Battery And Package Testing Meet IEC 1-2500Hz Vibration Test Systems provides a testing platform for packing and transportation simulation, mechanical shock, mission profile and any other real-world condition simulation. Utilizing the most advanced controller, the closed-loop system can accurately reproduce real-world vibration conditions on products from the industries like electronic, automotive, aerospace, aviation, etc.


Packaging:

Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.



We can customized different Vibration Shakers to different Vibration Force,Welcome your inquiry.
