Categories | Armored Fiber Optic Cable |
---|---|
Brand Name: | Yiyuan |
Certification: | ISO 9001;ISO 14001;OHSAS 18001 |
Place of Origin: | China |
MOQ: | 1KM |
Price: | Negotiation |
Payment Terms: | T/T, Western Union |
Supply Ability: | 500000km/month |
Delivery Time: | 30 working days after received your payment |
Packaging Details: | Wood coil strand |
Product Name: | Armored Fiber Optic Cable |
Fiber Count: | 2-288 Core |
OEM: | Accepted |
Application: | Outdoor Duct |
Jacket material: | PE PVC LSZH HDPE |
Color: | Black or customized |
Strength member: | Steel wire |
Installation: | Self-supporting Aerial |
Package: | Plywood Reel/customized |
795kg/Km Subsea Fiber Optic Heavy Duty Armoured Cable GYTA5333 4-144 Core Single Mode
Basic parameters: | |||
Country of Origin | China | Product name | armored fiber optic cable |
Brand name | Yiyuan | Type | GYTA5333 |
Fiber count | 4-144 core | Fiber mode | Single mode G652D |
Weight | 261-795kg/km | Outer diameter | 14.2-22.3mm |
Structure | Loose tube stranded; Multi armor and multi jacket(sheath) | Strength member | Aluminum tape; Corrugated steel tape; Round steel wire |
Sheath material | PE | Strength member | Phosphating steel wire |
Operation temperature | -20~+60℃ | ||
Other optional fiber | 9/125: G652D,G657 50/125 62.5/125 |
A-class optical fiber provide the high performance of transmission; PBT loose tube material has good hydrolysis resistance, the tube is filled with special ointment to protect the optical fiber; Phosphating steel wire as strength member to improve the good tensile strength performance; With good temperature characteristics; PE sheath anti-UV Three layers of armor and jacket,moisture-proof, crush resistant,durable;
![]() |
