Brand Name: | Joyruns |
Model Number: | 6mm --137mm |
Certification: | ISO9000 |
Place of Origin: | CHANGZHOU, CHINA |
MOQ: | 5 tons per size |
Price: | Negotiable |
Payment Terms: | TT OR LC |
Supply Ability: | 5000T PER MONTH |
Delivery Time: | 30DAYS |
Packaging Details: | Plastic packing, oiling, wooden box |
Standard: | ASTM A210 |
Grade: | A1. & C |
Type: | Cold drawing seamless Condenser tube |
OD. Range: | 6mm – 137mm |
Wall thickness: | 1mm-20mm |
Length: | Max length 12M |
Company Info. |
Changzhou Joyruns Steel Tube CO.,LTD |
Verified Supplier |
View Contact Details |
Product List |
ASTM A210 A1 25.4*2.11 Carbon heat exchanger cold drawing steel
tube
Our ASME SA 210 Gr. A1 Boiler Tubing is highly commended by the
clients for its on-time execution. Our clients can avail of this
ASTM A210 Grade A1Steam Boiler Piping in different grades and
dimensions as per the requirement and choice of the clients. This
ASTM A210 Gr. A1 Boiler Pipes Insulation is sternly inspected by
the best quality inspectors in order to deliver defect-free range
to the clients.
ASTM A210 Grade A-1 Carbon Steel Seamless Tubes are Medium Carbon Steel Tubes with max 0.27 % carbon content with a combination of max 0.93 % manganese.
These Tubes are most commonly used for general purpose applications worldwide. ASTM A210 Grade A-1 Tubes are ductile and strong Tubes with long-wearing properties.
These Tubes are manufactured as per ASTM Specification and commercially referred as carbon steel Tubes.
Specifications:
Grade and Chemical Composition ( % )
Grade | C | Mn | P | S | Si |
A-1 | ≤ 0.27 | ≤ 0.93 | ≤ 0.035 | ≤ 0.035 | ≥ 0.10 |
C | ≤ 0.35 | 0.29-1.06 | ≤ 0.035 | ≤ 0.035 | ≥ 0.10 |
Mechanical properties
Grade | Tensile Point | Yield Point | Elongation |
A-1 | ≥ 255(37) | ≥ 415(60) | ≥ 30% |
C | ≥ 275(40) | ≥ 485(70) | ≥ 30% |
![]() |
