| Categories | Extrusion Coating Lamination Machine |
|---|---|
| Brand Name: | Laiyi |
| Model Number: | ADRP/ASRP |
| Certification: | CE |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | $70,000-380,000 |
| Payment Terms: | L/C , T/T |
| Supply Ability: | Max 20sets per month |
| Delivery Time: | 90-150 days |
| Packaging Details: | Sea worthy packaging |
| type: | Paper lamianting machine |
| condition: | new |
| automatic gra: | automatic |
| driven type: | mechanical |
| voltage: | 380V |
| lifetime: | more than 10 year |
| Company Info. |
| JIANGSU LAIYI PACKING MACHINERY CO.,LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
1. Release Paper Extrusion Laminating Machine
2. Release Paper Extrusion Laminating Machine
Technical parameters
| Machine width | 1200/1400/1700mm | |
| Effective width | Max 1100/1300/1600mm | |
| Machine speed | 300-350m/min | |
| Screw diameter | LD-90mm/LD-100mm/LD-115mm,Auto lifting type extruder | |
| Extruder output | Max 300kg/h,400kg/h or 550kg/h | |
| Used resins | Coated resins like LDPE/LLDPE/PP/EVA | |
| Coating thickness | 8-45μm | |
| Maxdiameter | Unwinder:Φ1200mm;Rewinder:Φ1200mm | |
| Basic material | Paper(35-200gsm) | |
| Dimension(L*W*H) |
Single:19.2*(9.5-12)*4.5m |
1) Double Shaft-less paper roll stands suitable for 3-6 inch paper core,automatic lift ,easier operation .
2) Auto splicer device realize paper in 150-300 m/min speed exchange without decrease machine line speed
3) Ultrasonic type EPC system,makes frequent replacement materials operation more simple
4) Hydraulic lamination structure design , can make coating thinner and firm .
5) Trimming device make the finished coated paper rolls even
6)Special cutting knife and rewinder design makes high speed rewinding shafts exchange possible
FAQ
Q: What's the size of your machine?
A: From 1200mm to 2500mm, we can design and make according to your
requirement.
Q: Which machine should I choose?
A: Our extrusion laminating lines cover single side, double sides,
muti-layer co-extrusion machines for roll-based paper, films,
metalized films, aluminium foil, clothes, woven and non-woven
fabric, etc
Q: How to carry out the machine acceptance?
A: After the installation of the machine is finished in our factory,
the representive(s) of your company will be invited to inspect the
test running before shipment.
Q: Does your machine have alarm devices?
A: Of course, we have warning lights in each part of our machine for
paper break alarm and fault alarm.
Q: How can I install the machine?
A: Our engineers will provide service overseas after you received
the shipped machine.
" Professional qualifications to create brand" is Laiyi's business objective!
"Create excellece by quality, prvide service with honesty" is
Laiyi's business prupose!
|
