125V 250V AC Miniature Cartridge Fuse Time Lag 100mA-10A Micro Pico Fuse

2x7mm Axial Wire Resistor Resistance Time Delay Slow Blow Acting Time-lag Pico Micro Fuse

Series:2mm Fuses

Keyword:No.212/2×7mm time-lag micro pico fuse

Time - current features:Time-Lag (T)
Breaking Capacity: 535A@150/250VAC,50A@150/250VAC
Standard:UL248-14
Approvals: cULus,cURus,TUV,CQC,PSE,KC

Materials:shell-ceramic tube, metal cap-nickel-plated brass, lead cap-nickel-plated cap, tin-plated copper wire
Operating Temperature:-55℃ to +150℃
Soldering Parameters:260℃.≤10 sec (Wave Soldering),350℃.≤2 sec (Hand Soldering)
Soldering Peak:260℃. 10 sec.,280℃. 5 sec.
Storage Conditions:+10℃ to +60℃
Relative humidity:≤75% yearly average Without dew, maximum 30 days at 95%

Application of Slow Blow Acting Pico Micro Fuse

Mainly used in emergency lights, battery protection, LED drive power, adapters, LCD displays, low-power medical equipment

Note: (1) Permissible continuous operating current is ≤100% at ambient temperature of 23°C (73.4°F)

(2) The cURus and cULus certification by 125V and 250V; the others certification only by 250V.

(3) The current values used for calculating I2T should be within the standard range of 8ms ~ 10ms.
