0207 0309 3W Fixed Wire Wound Resistor 10 Ohm Wire Wound Resistor For LED Lighting

MELF Surface Mount Wirewound Cylindrical Fixed Resistor 0207 0309 0411 0.25~3W For LED Lighting


I Cylindrical Fixed Resistor APPLICATION INFORMATION

When the resistor dissipates power, a temperature rise above the ambient temperature occurs, dependent on the thermal resistance of the assembled resistor together with the printed circuit board. The rated dissipation applies only if the permitted film temperature is not exceeded. These resistors do not feature a limited lifetime when operated within the permissible limits. However, resistance value drift increasing over operating time may result in exceeding a limit acceptable to the specific application, thereby establishing a functional lifetime.

II Cylindrical Fixed Resistor Applications

- Water heaters
- Welding equipment
- Power supplies for plasma cutters
- Gas and diesel powered engine controls
- Electric meters
- Utility meters
- Communications equipment
- Power/network/phone distribution equipment
- Lighting
- Thermostats and HVAC controls

III Cylindrical Fixed Resistor Features

1. Good performance of anti-surge impact.
2. Good fusing consistency
3. Small size , all-welded construction, lead free and easy to install.
4. Excellent safety performance
5. High temperature molded encapsulation.
6. Flex termination for absorbing thermal expansion

7. Fusible resistor for constant voltage designed for overload protection
8. Special trimming to provide the fusing characteristic
9. Flame retardant coating


IV Cylindrical Fixed Resistor Construction

1.Terminal

2.Marking

3.Insulation coating

4.Matrix

5.Wire wrapping

V Cylindrical Fixed Resistor Electrical Parameters

Remarks: L is the total length of the double cap, D is the thickness of the paint,

D1 is the total height of the inner cap, D2 is the total height of the outer cap,

S is the thickness of the iron cap, and C is the width of the outer cap.

VI Cylindrical Fixed Resistor Packaging reel sizes (unit:mm)

OCP Overcurrent Protection

Fuse
Fuse Link
Thermistor
Film Resistor

Wirewound Resistor

Inductor
