MAZS-(0.3-2)×1300mm Metal Coil Slitter for Material of coils: carbon steel, stainless steel, galvanized plate and so on

1. Product name:

MAZS-(0.3-2)×1300mm Metal Coil Slitter for Material of coils: carbon steel, stainless steel, galvanized plate and so on.

2. Main technical parameter:

Material of coils: carbon steel, stainless steel, galvanized plate, colored steel plate

Strip thickness: (0.3-2) mm

Max. Strip width: 1300mm

Inner diameter of coils: ≥Φ508mm

Outer diameter of coils: Φ1800mm

Max. Coil weight: 15000Kg

Slitter motor: 55KW DC motor

Slitter shaft: Ф205 x 1400mm

Disc knives on slitter shaft: ID205mm x OD310mm x 10mm, 6CrW2Si(H13, SKD-11).

Separating disc: ID75 x OD180mm x 6mm, 65Mn

Tensioning provided by strip passing through frictional wool felt wrapping around wooden plates.

Recoiler block: Ф508 x 1400mm

Recoiler motor: 75KW DC motor

Electric control: Eurotherm 590 DC driver cabinet plus control panels.

Slitting speed: max 80m/min, adjustable.

3.Decoiler and uncoiler details

WUXI MAZS MACHINERY SCIENCE AND TECHNOLOGY CO.,LTD. is a high-tech enterprise which is engaged in developing, manufacturing and trading. We have one science part and four production bases. Our main products are metallurgy machinery such as metal coil cold rolling mill lines, slitting lines, HF welded pipe mill lines, cut-to-length lines, roll forming machines, etc.

Which not only has been sold in all parts of China but also has been exported to South Asia, Middle East, Europe, American, etc.

We are the council member of China Welding Association, the standing council member of China Metal Structure Association, National Spark Plan High-tech Enterprise, Jiangsu Star Enterprise, Jiangsu Comprehensive Management Demonstration Enterprise. We are the manufacturing enterprise participated in the above mentioned Equipment Standard. We take the lead in passing ISO9000 quality system certification and CE certificate.

Our unchangeable policy: “Proceed from Optimum in Everything; and Satisfy Customer’s Demand and Expectation with High Quality Products and Excellent Service.”

Bearing grateful heart always in mind, we are willing to cooperate with all customers from home and abroad to create a new brilliance together.
