1B6-833 Air Ride Springs 579912833 Goodyear Single Convoluted

Categories Goodyear Air Spring
Supply Ability: 1000pcs/week
Payment Terms: T/T, Western Union,Paypal or Others
Place of Origin: Mexico
Brand Name: Goodyear
Certification: ISO/TS16949, ISO9001
MOQ: 3 pieces
Packaging Details: Strong Carton Box or as Customers Requirement
Delivery Time: 3-8 Working Days
Model Number: 1B6-833
N.W.: 1.2 Kg
Warranty: One Year
Pressure Ability: 0.2-0.8 M PA
Maximum Diameter: 165 mm
Trademark: Goodyear
Transport Package: Cartons
Specification: 16*16*16 cm
Origin: Mexico
HS Code: 8708809000
Port: Huangpu, China
Material: Rubber and Iron
Car Make: Hendrickson
Position: Front and Rear
OEM: Yes
Type: Shock Absorber
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

1B6-833 Air Ride Springs 579912833 Goodyear Single Convoluted

Goodyear 1B6-833 Air Spring Single Convoluted Air Spring 579912833 with Aluminum Plate


OEM Original Manufacturer:


Goodyear Original:1B6-833


The usual below kinds of Goodyear air spring we have

Nut/blind nut
Top cover screw (nut) teeth: 2 xM8-16UNC
Top cover screw center distance: 44.5 mm
Screw (nut) teeth of the bottom cover: 2 xM8-16UNC
Center distance of bottom cover screw: 44.5mm

Air hole/air inlet/air connector
Exhaust hole/air inlet: G1 / 4
Center distance between nut and air inlet: 22.25 mm

Cover
Top cover diameter (width): 105.4 mm
Diameter of bottom cover (width): 105.4 mm

ub rubber bellows
Rubber bellows diameter: 150mm
Compressed height: 71 mm
Maximum height: 122 mm
Working stroke: 71 mm

Bumper block/bumper block
No bumper block

Twist/waist ring
Belt loop: Without belt loop


Replaces following OEM air springs:

ContiTech Part number: FS 70-7 2681015000

ContiTech Part number: FS 70-7 Cl 2681015000

ContiTech Part number: FS 70-7 1/4 M8

ContiTech Part number: FS 70-7 G1/4 M8

ContiTech Part number: FS 70-7 Cl G1/4

ContiTech Part number: FS 70-7 Cl G1/4 M8

ContiTech Part number: FS 70-7 CI/ FS70-7CI/ FS707CI

ContiTech Bellow Part number: FS 70-7 1 FS70-7 /FS707

Firestone No. Part number: W01-M58-6155 1 WO1 M58 6155 1 W01M586155

Firestone Style Part number: 131

Enidine Part number: YM-FS 70-7-0160/ YM FS 70-7-0160 1 YMFS70-7-0160

Enidine Part number: YM-FS 70-7 CI G1/4 M8

Enidine Part number: YI-FS 70-7-731/ YI FS 70-7-731 1 YIFS70-7-731

Enidine Part number: YI-FS 70-7 CI 1/4NPT 3/8-16UNC

Goodyear Part number: 1B6- 83311B6833 1 1B6833

Goodyear Flex No. Part number: 579-913-510 1579 913 510/ 579913510

Goodyear Part number: 1B6- -530 / 1B6 530/ 1B6530

Goodyear Flex No. Part number: 579-913-510 1579 913 510/ 579913510

Enidine Part number: YI-1B6- -5301 YI 1B6530/ Yl1B6530

Phoenix Part number: SP1 B 05 1 SP1B05

Bosch Part number: 822419002

Festo Part number: EB-165-65/ EB 16565/ EB16565

Weforma Part number: WBE 200-E1 1 WBE200-E1 / WBE200E1

Vigor Part number: 1B 50021 1B5002

Vigor Bellow Part number:1B70-7 /1B70 7 /1B707

VKNTECH Part number:1B 70701 1B7070

VKNTECH Bellow Part number: 1B70-7 /1B70 7 /1B707

EAA Part number:1E70-7 /1E70 7 /1E707

EAA Bellow Part number:1E70-7 /1E70 7 /1E707

HONGLI Part number: JBF100/96-1/ JBF100 961/ JBF100961

CHENGUANG Part number: 150086J-1 1150086J11150086J1


5799128310001920095541YENIDINE YI-1B6-831ENIDINE YI-1B6-831
1B6-83320263189N1B6-8331B6-833
5799128330001920095542YENIDINE YI-1B6-833ENIDINE YI-1B6-833
5799128340009020806000YC 1B6-833C 1B6-833
1B6-83520488587N1B6-8351B6-835
5799128350001920117074YENIDINE YI-1B6-835ENIDINE YI-1B6-835
1B7-84020680822N1B7-8401B7-840
5799128400001920095543YENIDINE YI-1B7-840ENIDINE YI-1B7-840
5799128500000020384830Y1B8-8501B8-850
5799128500001920095544YENIDINE YI-1B8-850ENIDINE YI-1B8-850
5799128600001920117076YENIDINE YI-1B8-860ENIDINE YI-1B8-860
5799125280009020811600YC 1B6-530C 1B6-530
5799125290009020811601YC 1B6-535C 1B6-535
1B6-53020095484N1B6-5301B6-530
5799125300001920095485YENIDINE YI-1B6-530ENIDINE YI-1B6-530
1B6-53120095486N1B6-5311B6-531
5799125310001920095487YENIDINE YI-1B6-531ENIDINE YI-1B6-531
1B6-53220095488N1B6-5321B6-532
5799125320001920095489YENIDINE YI-1B6-532ENIDINE YI-1B6-532
5799125330000020095490Y1B6-5331B6-533
1B6-53520095491N1B6-5351B6-535
5799125350001920095492YENIDINE YI-1B6-535ENIDINE YI-1B6-535
1B6-53620095493N1B6-5361B6-536
5799125360001920095494YENIDINE YI-1B6-536ENIDINE YI-1B6-536
1B6-53820065951N1B6-5381B6-538
5799125380001920095496YENIDINE YI-1B6-538ENIDINE YI-1B6-538

Goodyear 1b6-833 Air Spring Single Convoluted Air Spring 579912833 with Aluminum Plate
Goodyear 1b6-833 Air Spring Single Convoluted Air Spring 579912833 with Aluminum Plate
Goodyear 1b6-833 Air Spring Single Convoluted Air Spring 579912833 with Aluminum Plate

Cheap 1B6-833 Air Ride Springs 579912833 Goodyear Single Convoluted for sale
