Brand Name: | Suntech |
Model Number: | Anti twisting steel wire |
Certification: | ISO |
Place of Origin: | Ningbo,China |
MOQ: | 500m |
Price: | Get the newest price |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 20000 meter per day |
Delivery Time: | 7-10 days after payment |
Packaging Details: | Reels and containers |
Steel Grade:: | Steel Wire Rope |
Wire Dia: | 18mm |
Surface: | Galvanized |
Breaking Force: | 210KN |
Manufacturing Experince:: | 15 Years |
Type: | Anti-twisting Galvanized Steel Wire Rope |
Company Info. |
Ningbo Suntech Power Machinery Tools Co.,Ltd. |
Verified Supplier |
View Contact Details |
Product List |
Anti twisting Braided Steel Pilot Wire Rope Conductor Stringing Rope 12 Strands 18mm
Suntech Power is a manufacturer of research,development, production and sales: Stringing Block, Hoisting Tackle,
Wire Grip, Reel Stand,Inspection Trolleys, Tightening Tools, Connector, Shackle, Lifter, Head Boards For Conductors,
Mesh Sock Joints, Powered-winch, Press-machine and other construction tools and equipment company for electric
power construction. At the same time, agents of various imported construction tools and power equipment.
18MM Anti twisting braided steel wire rope
Item No. | Nominal diameter | Breaking Load (KN) | Single strand diameter (mm) | Normal T/S (N/mm²) | Net Weight (kg/1000m) | |
18209A | 18 | 206.00 | Φ4.0 | 1960 | 1060 |
Anti-twisting braided wire rope with high strength hot dip
galvanized steel quality air processed by the special process of
special woven rope line. It has high strength, good flexibility,
corrosion rust-proof, not to fight the golden hook, and difficult
to tie, long life and so on. Tension applied to pay-off power lines
construction, lifting equipment with the balance shaft and the tail
rope of mine, port and other major lift crane wire rope does not
rotate when the required place.
Item no. | Normal Diameter (mm) | Structure | Breakage tension(kN) | Standard Length (m) | Diameter of spool (mm) | Total weight (kgs) |
YL9-12x19W | 9 | 12 Strands | 55 | 1000 | 850 | 294 |
YL10-12x19W | 10 | 12 Strands | 55 | 1000 | 850 | |
YL11-12x19W | 11 | 12 Strands | 80 | 1000 | 1000 | 454 |
YL13-12x19W | 13 | 12 Strands | 120 | 1000 | 1100 | 642 |
YL16-12x19W | 16 | 12 Strands | 158 | 1000 | 1250 | 886 |
YL18-12x19W | 18 | 12 Strands | 210 | 1000 | 1400 | 1154 |
YL20-12x29Fi | 20 | 12 Strands | 250 | 1000 | 1400 | 1394 |
YL22-12X29Fi | 22 | 12 Strands | 320 | 1000 | 1400 | 1258 |
YL24-12x29Fi | 24 | 12 Strands | 360 | 800 | 1440 | 1474 |
YL28-12x29Fi | 28 | 12 Strands | 480 | 500 | 1600 | |
YL30-12x29Fi | 30 | 12 Strands | 540 | 500 | 1600 | |
YL20-18x19W | 20 | 18 Strands | 300 | 1000 | 1440 | 1368 |
YL22-18X29Fi | 22 | 18 Strands | 389 | 800 | 1440 | |
YL24-18x29Fi | 24 | 18 Strands | 440 | 800 | 1440 | |
YL28-18x29Fi | 28 | 18 Strands | 580 | 500 | 1600 | 1655 |
YL30-18x29Fi | 30 | 18 Strands | 658 | 500 | 1600 | 1900 |
About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either
![]() |
