2 Port 64bit MAC 1 1000 Base Tx Port EPON ONU For Town Village

Categories EPON ONU
Brand Name: Hioso
Model Number: HA7200D
Certification: CE, RoHS, CCC
Place of Origin: China, Guang dong
MOQ: 1
Price: Negotiable
Payment Terms: T/T, D/P, Western Union
Supply Ability: 5000pcs/month
Delivery Time: 2-12 work days
Packaging Details: 30X25X15 CM
Itme: Epon onu
Apply: Fttx solutions
Max distance: 20 Km
Power: DC 12V
MTBF: 100000h
MAC: 64K
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

2 Port 64bit MAC 1 1000 Base Tx Port EPON ONU For Town Village

Ethernet 2 Port Epon Onu 10 / 100 Base Tx Port + 1 1000 Base Tx Port


Overview


HA7200D ONU is an Ethernet product, with a fixed 10/100BASE-TX port and a 10/100/1000BASE-TX port. HA7200D works with central device OLT to implement integrated management, long-distance fault location and decrease maintenance workload.


Feature

  • Apply to IEEE802.3/802.3ah
  • Support auto discovery and auto register (real-time operation)
  • Support DBA and multi types SLA
  • Support IEEE802.1D RSTP
  • Support IGMP Snooping V2 multi-broadcast function
  • Support EMI and ESD identification
  • 64bit MAC
  • Support VLAN
  • Support multi LLID
  • Support user end auto time synchronization based at SNTP
  • Support OAM and remote management

Technical Parameter

ParameterSpecification
Wavelength1310 (TX)/1490 (RX)
Optical power-1~+4dBm
Receiving sensitivity-24dBm
Max transmission distance20 km
MAC Table64
Cache space1.25MB
Number of LLID1--8
MTBF100,000 hours
EPON trait

Support IEEE802.3ah

Support Dynamic Bandwidth Allocation (DBA)

Support ONU auto-searching and automatic registration (real-time operation)

Standard and Protocol

Support IEEE802.3, IEEE802.3u, IEEE8023.ab

Support IEEE802.1q WLAN

Support IEEE802.1p QOS

Network managementCooperating with center OLT, implement management configuration and software upgrade to ONU


Our Service
Fast Reply: Client’s query to be replied within 24 hours.
Quality Control: Our QC team will check the ordered products one by one before shipment.
Return Policy: Faulty products return accepted,but postage mishandling or damage caused by installation not be covered.
Package: Standard export carton or customized packing solutions accepted upon client’s requirement if there is any.
Tech Supports: Tech assistance during the installation or application procedure.
Company Introduction
HiOSO Technology Co., Ltd. was founded in 2002, being dedicated to the research, production and sale of optical communication network products based on FTTH and FTTD.Our main products include EPON systems, fiber optic media converters, CWDM system equipment, digital video optical transceivers, converter racks, single/multi-mode converters, PDH and fiber modems.
