Name: 586um Pixel Hyperspectral Imaging Camera With CMOS Detector
Brand: CHN spec
Price: 1 USD

Categories

Hyperspectral Imaging Camera

Brand Name:

CHN spec

Model Number:

FS-12

Certification:

Place of Origin:

China

MOQ:

Payment Terms:

L/C, T/T, Western Union, MoneyGram

Supply Ability:

1000 per month

Delivery Time:

5-7 days

Packaging Details:

carton box

Price:

negotiable

Spectroscopic method:

Grating spectroscopy

Wavelength Range:

400-1000nm

Spectral bands:

1200

Spectral sampling/pixel:

2.5nm (max. 1.5nm)

Slit width:

25um

Pixel Size:

5.86um

Imaging speed:

Full Spectral range 41Hz, 390Hz after ROI

Detector:

CMOS

5.86um Pixel Hyperspectral Imaging Camera With CMOS Detector

Hyperspectral Imaging Camera equal to Specim Hyperspectral Camera with Competitive Price

Hyperspectral Imaging Camera Advantages

1. Spectral range:400-1000nm, spectral sampling/pixel 2.5nm, max. 1.5nm (Changing the slit width can achieve higher spectral resolution, but will affect the signal strength)

2. Imaging speed: Full Spectral range 41Hz,390Hz after ROI

3. Machine vision, color measurement, near-infrared detection hyperspectral solution

4. Color difference test : print, textile and other industries surface color test, texture detection, with special light source and control system, the repeatability of single pixel of color measurement can reach dE*ab<0.1.

5. Support multi-region ROI

Hyperspectral Imaging Camera Working Principle

Line Scan Measurement

Hyperspectral Imaging Camera Working Principle

Hyperspectral Imaging Camera Technical Parameter

Model	FS-10	FS-12	FS-13	FS-15
Spectroscopic method	Grating	Grating	Grating	Grating
Spectral region	400-700nm	400-1000nm	400-1000nm	900-1700nm
Spectral band	600	1200	1200	254
Spectral resolution	2.5nm	2.5nm	2.5nm	8nm
Slit width	25um	25um	25um	25um
Transmission efficiency >50%	>50%	>60%	>60%	>60%

Stray light	<0.5%	<0.5%	<0.5%	<0.5%
Spatial pixel number	1920	1920	1920	320
Pixel size	5.86um	5.86um	5.86um	30um
Imaging speed	Full band 41Hz 390Hz can be achieved after ROI	Full band 41Hz 390Hz can be achieved after ROI	Full band 128Hz 3300Hz can be achieved after ROI	200Hz

Detector	CMOS	CMOS	CMOS	InGaAs

SNR(Peak)	500/1	600/1	600/1	600/1

Camera output	USB3.0	USB3.0	USB3.0	Gigabit network

Camera interface	C-Mount	C-Mount	C-Mount	C-Mount
Accessories	USB3.0 transmission line	USB3.0 transmission line	USB3.0 transmission line	USB3.0 transmission line
ROI	Single area	Single area	Multiple area	Single area

Hyperspectral Imaging Camera Application

Hyperspectral imaging camera is widely used to scan the sample and get its reflectance under each pixel. It is no limit on the measurement distance. The result can be used for color quality control or material seperation by different content. It can be used in lab or installed in the production line. It is widely used in agriculture industry, food insutry, screen industry, textile industry and many other industries.

CHNSpec Technology （Zhejiang）Co.,Ltd. was found in 2008, and we are specializes in the R&D, production and sales of colorimeters, spectrophotoemters, haze meters, gloss meters and spectral analysis instruments, and is a leading producer in the color measurement field in China.Oue products have been widely used in plastic, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic, optical image test industries and the field of scientific research, school and laboratory..We are national high technology enterprise.Till September of 2018, Hangzhou CHNSpec Technology has received 11 invention patents ,3 software copyright patents and one American invention patent.In addition there are more than 10 invention patents in the announcement state. We have published more than 20 papers which more than 10 papers in SCI and EI and others are in the national first grade journal of science and research.

Our goal is to exceed the expectations of every client by offering outstanding customer service, increased flexibility, and greater value, thus optimizing system functionality and improving operation efficiency.We wish create value for customers and achieve win-win and common development and open a new era.

CHNSpec’s one-stop service gives you complete control over the sourcing, distribution, sales, delivery and after-sales services. In addition, our attention to detail and quality of work, paired with years of industry experience, make us your perfect partner to produce outstanding results. We also offer a significant security advantage to you as we are the only organization with trusted and experienced key staff involved in the product sales. It also means effective cost control and short lead times between sales and deliveries. We put customers upon everything else, and we are trying our best to satify your all needs.We sincerely support the best services for out customers

Our quality assurance program ensures that all products continuously conform to standards, from when it was sourced to when it is awaiting delivery at our warehouse. All of our products are being tested by QC and verified by 3rd party to ensure all the specifications are strictly met.

CHNSpec will always provide on time delivery. From order taking to deliveries, we ensure all products are sent out to esteemed customers on time. Before-sales and after-sales service is paramount to us, and constantly ingrained into our staff. All CHNSpec personnel are well-equipped with deep product knowledge and trained in the marketing and sales aspect of our products. Lastly, all product queries are important to us, no matter the size and scale of it.
