Brake Pad Friction Coefficient Wear Rate Testing Machine Mechanical Strength Tester 380V

Brake pad friction coefficient wear rate testing machine Mechanical Strength Test Power 380V

Standard:

In strict accordance with GB5763-98 standard, in keeping the basic principle and structure of Japanese HP - S prototype machine, combined with modern technology improvement design.

Test method:

Gravity code type calibration device makes the measurement more accurate;The measurement accuracy is improved significantly by canceling the damping cylinder.The friction force and friction coefficient are measured and calculated manually.A new force measuring method was adopted, and the damping device was cancelled, so the measuring accuracy was improved.

Technical parameters:

Motor power: 7.5KW

Heating power: 4.0KW

Power: 380V

Friction disc: material HT250

Hardness HB180 - 220, pearlite structure

Spindle speed: 400-500r /min

Loading: small surface pressure: 0.3Mpa

Surface pressure: 0.98 Mpa

Dimensions: 1750×1250×1420

Weight: 1000kg

Parameter:
