| Categories | Multihead Combination Weigher |
|---|---|
| Brand Name: | UUPAC |
| Model Number: | TY-A-M/10-4 |
| Certification: | CE ISO9001 |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | 5000-6000USD |
| Payment Terms: | T/T |
| Supply Ability: | 200 sets per month |
| Delivery Time: | 15 working days |
| Packaging Details: | packaged with the wooden case |
| weighing range: | 5-1500g |
| hopper volume: | 1.6L/2.5L |
| control system: | PLC/MCU |
| HMI: | 7/10 Inch touch screen |
| Application: | Sticky food/seafood/frozen food |
| Product: | Multiheads weighers |
| Hoppers: | 10/14/20 |
| Surface: | Dimple |
| Package: | plywood case |
Application:
Suitable for quantitative weighing of sticky material such as gum
drop, spun sugar, meatball, vegetable, screw etc.
Functional characteristics
Double door mechanical device for weighing buckets, facility to set
up operation angle for the motor according to the volume properties
of the material.
According to the characteristic of material can be fine adjusted
the opening and closing speed of the bucket door to avoid crush and
block.
Main Features:
1, Original program can be restored.
2, Easy cleaning and maintenance with clean function, all hoppers can stay open.
3, Piece counting function.
4, IP65 certificate.
5, Unqualified weight reject.
6, Step motor angle can be set according to different product.
7, 99 program can be preset.
8, Stagger dump prevents products blockage.
Technical Parameters:
| Model | TY-A-M/P-10-4 | TY-A-M/P10-2 |
| Weighing Range | 5-200g | 20-1000g |
| Accuracy | x(0.5) | x(0.5) |
| Min.Scale Interval | 0.1g | 0.1g |
| Max.Speed | 120p/M | 120p/M |
| Hopper Volume | 0.8L/0.5L | 1.6L/2.5L |
| Control Sytem | MCU/PLC | MCU/PLC |
| HMI | 7"(Standard)/10" color touch screen | 7"(Standard)/10" color touch screen |
| Power Supply | AC220V±10%/50~60Hz,1.5KW | AC220V±10%/50~60Hz,1.5KW |
| Packing Dimension | 1370()*1060(W)*1105(H)mm | 1140()*1140(W)*1853(H)mm |
| Gross Weight | 240kg | 500kg |
FAQ:
1. How to install the new machine?
our machines are designed easy for installation; Installation video
is also available. If needed, we'll arrange professional engineer
to service overseas if buyers bear related cost.
2. How to solve the problems during using the machines?
We have experienced after-sales team ready to solve the problems
for our buyers. Buyers describe the problems to us by email or
telephone; sometimes we need you to supply the problem pictures and
videos for our engineers for reference, we will try to discuss with
buyers and try to get the most effective solution in shortest time.
If necessary, we can arrange the most professional engineer to go
to buyer's factory for solving problems as soon as possible.
3. What's your warranty period and spare parts supply?
We offer one year warranty and life-long maintenance. In the first
year, if any parts broken not occurred by human factor and parts
not in the list of 1% free spare parts, we will supply the new
replacement parts freely.
4. Do you supply OEM service?
Yes. OEM service is available. Our designer would make your private
idea into being. We will protect your sales area, ideas of design
and all private information belonged to you.
Certificate
