A36 Steel Welded Steel Grating 25×5 Steel Open Mesh Flooring

highways A36 Steel ASTM A123 Standard Smooth Surface Welded Steel Grating

Welded Steel Grating Introduction:

Bar grating in Light or Heavy Duty welded steel grating:

Light Duty steel grating ranges in size from 3/4" x 3/16" to 2-1/2" x 3/16"
Heavy Duty steel grating ranges in size from 1" x 1/4" to 6" x 1/2"

Light Duty Steel Grating Press Lock - DT Series:

Produced like aluminum press lock because it is made up of interlocking perpendicular bars
Hydraulic pressure (not welding) is used to bond the slotted bars together, locking the deep cross bar into the notched bearing bar
Has a smooth, clean look due to a flush top rectangular cross bar
Slip resistant surfaces for floor grating available upon request

*Not for rolling loads

Light Duty Steel Press Lock bar grating offers strong lateral stability. This steel grating is used in architectural design because of its clean look and tight spacing. The 1/4" and 1/2" openings of the steel grating conform to the “American with Disabilities Act” (July 1991).

Light Duty Riveted Steel Grating - R Series:

Rugged, reliable, and durable bar grating
Made by joining straight bearing bars and bent connecting bars with rivets
Connecting bars increase lateral stability and load capability
Ideal steel grating choice for when strength and rigidity is needed
Slip resistant surfaces available upon request

Heavy Duty Welded Steel Grating - W Series:

Heavy Duty Welded Steel bar grating is a great selection when strength is required in architectural and industrial applications. This type of steel grating is produced when carbon steel or stainless steel bearing bars are welded to cross rods at each connecting point. Heavy Duty Welded Steel grating can meet vehicle-loading requirements of AASHTO and is made to handle heavy rolling loads.

Heavy Duty Riveted Steel Grating - R Series:

Perfect for vehicle bridge decks and bridges, Heavy Duty Riveted Steel grating is an excellent choice when a great deal of strength and rigidity is needed. Steel grating is available as a slip resistant surface upon request.

Rugged, reliable, and durable bar grating
Made by joining straight bearing bars and bent connecting bars with rivets
Connecting bars increase lateral stability and load carrying capability

Quality Standard Qindelin follows in production:

Steel Grating Standard: China YB/T4001-1998

America ANSI/NAAMM (MBG531-88)

Britain BS4592-1987

Australia AS1657-1992

Steel Standard: China GB700-88 / ASTM (A36) / BS4306 (43A)

Hot Dip Galvanizing Standard: China GB/T13912-92 / ASTM (A123) / BS729

Welded Steel Grating Specification:

Series No.	Verticle Bar Spacing	Horizontal Bar Spacing	Specification of Supporting Flat Steel (Width X Thickness)
			20¡Á3	25¡Á3	32¡Á3	40¡Á3	20¡Á5	25¡Á5
1	30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
		50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
2	40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
		50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
3	60	50	-	G253/60/50	G253/60/50	G403/60/50	G205/60/50	G255/60/50
Series No.	Verticle Bar Spacing	Horizontal Bar Spacing	Specification of Supporting Flat Steel (Width X Thickness)
			32¡Á5	40¡Á5	45¡Á5	50¡Á5	55¡Á5	60¡Á5
1	30	100	G325/30/100	G405/30/100	G455/30/100	G505/30/100	G555/30/100	G605/30/100
		50	G325/30/50	G405/30/50	G455/30/50	G505/30/50	G555/30/50	G605/30/50
2	40	100	G325/40/100	G405/40/100	G455/40/100	G505/40/100	G555/40/100	G605/40/100
		50	G325/40/50	G405/40/50	G455/40/50	G505/40/50	G555/40/50	G605/40/50
3	60	50	G325/60/50	G405/60/50	G455/60/50	G505/60/50	G555/60/50	G605/60/50

Specification of Common Standard Steel Bar Grating
Series No	Vertical Bar Spacing	Horizontal Bar Spacing	Specification of Supporting Flat Steel Width X Thickness (mm) (mm)
Series No	Vertical Bar Spacing	Horizontal Bar Spacing	20× 3	25× 3	32× 3	40× 3	20× 5	25× 5
1	30	100	G203/ 30/ 100	G253/ 30/ 100	G323/ 30/ 100	G403/ 30/ 100	G205/ 30/ 100	G255/ 30/ 100
1	30	50	G203/ 30/ 50	G253/ 30/ 50	G323/ 30/ 50	G403/ 30/ 50	G205/ 30/ 50	G255/ 30/ 50
2	40	100	G203/ 40/ 100	G253/ 40/ 100	G323/ 40/ 100	G403/ 40/ 100	G205/ 40/ 100	G255/ 40/ 100
2	40	50	G203/ 40/ 50	G253/ 40/ 50	G323/ 40/ 50	G403/ 40/ 50	G205/ 40/ 50	G255/ 40/ 50
3	60	50	-	G253/ 60/ 50	G323/ 60/ 50	G403/ 60/ 50	G205/ 60/ 50	G255/ 60/ 50
			32 × 5	40× 5	45× 5	50× 5	55× 5	60× 5
4	30	100	G325/ 30/ 100	G405/ 30/ 100	G455/ 30/ 100	G500/30/100	G555/ 30/ 100	G605/ 30/ 100
4	30	50	G325/ 30/ 50	G405/ 30/ 50	G455/ 30/ 50	G500/ 30/ 50	G555/ 30/ 50	G605/ 30/ 50
5	40	100	G325/ 40/ 100	G405/ 40/ 100	G455/ 40/ 100	G500/ 40/ 100	G555/ 40/ 100	G605/ 40/ 100
5	40	50	G325/ 40/ 50	G405/ 40/ 50	G455/ 40/ 50	G500/ 40/ 50	G555/ 40/ 50	G605/ 40/ 50
6	60	50	G325/ 60/ 50	G405/ 60/ 50	G455/ 60/ 50	G500/ 60/ 50	G555/ 60/ 50	G605/ 60/ 50

Welded Steel Grating Applications:

Uses: Stainless steel bar grating is mainly used in chemical industry, food processing, hydro processing and other industries as listed:

Power plant;

Chemical plant;

Oil Refinery;

Steel plant;

Machinery plant;

Paper-making factory;

Cement plant;

Civil engineering;

Wastewater treatment;

Pharmacy industry;

Food processing.

Welded Steel Grating Feature:

The products enjoy the features of high strength, light structure, high bearing, convenience for loading and other properties.

The excellent self-cleaning characteristics of plain surface grating make it suitable for the majority of applications. In the presence of fluids or materials that could cause the top surface of the grating to become wet or slippery, specification of the optional serrated surface should be considered. When serrated grating is specified, the bearing bar depth must be 1/4″ greater than the sizes shown on the load tables to provide the equivalent strength of non-serrated gratings.

Product Tags:

A36 Steel Welded Steel Grating

A36 steel open mesh flooring

25×5 steel open mesh flooring

A36 Steel Welded Steel Grating 25×5 Steel Open Mesh Flooring

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	Anping Yuanfengrun Mesh Products Co., Ltd.
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Welded Steel Grating
Brand Name:	X MESH
Model Number:	X MESH-0151
Certification:	ISO9001:2015
Place of Origin:	Hebei P.R. China.
MOQ:	50pcs
Price:	USD20.50-50.50/pc
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	8500pcs/week
Delivery Time:	5-7days
Packaging Details:	Wrapped with plastic film and pallet packing
Width:	1000mm
Application:	highways
Type:	Smooth Surface
Length:	6000mm
Color:	Silver
Standard:	ASTM A123
Series:	Hot Galvanized
Bearing Bar:	25mm x 3mm
Cross Bar:	5mm
Material:	A36 Steel
