Double Side FR-4 Multilayer 6oz SMT Prototype Assembly

Categories PCB Assembly Prototype
Brand Name: HNL-PCBA
Model Number: PCB Assembly03
Certification: ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
Place of Origin: CHINA
MOQ: 1 PC
Price: Negotiable
Payment Terms: T/T, Western Union, L/C, MoneyGram
Supply Ability: 10,000,000 Point /Day
Delivery Time: 1-7days
Packaging Details: ESD packaging with carton box
Product name: PCB Assembly Prototype
Material: Fr-4, High-Tg
Copper thickness: 0.3oz. 0.5oz ..... 6oz
Max Board size: 700x610mm; custom size
Min. line spacing: 0.030mm
Board thickness: 0.3-3.5mm
Surface finishing: HASL,OSP,ENIG,HASL Lead Free,Immersion Gold
Application: communication equipment, industrial control, consumer electronics, medical equipment, aerospace, light-emitting diode lighting, automotive electronics
Item: Custom Circuit Board,OEM/ODM
Layer: 1-30L,2 Layer,4 Layer,1-18
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Double Side FR-4 Multilayer 6oz SMT Prototype Assembly

FR4 HASL Lead Free Double Side SMT Manufacturing PCB Assembly Prototype

PCB Assembly Prototype Introduction


Prototype printed circuit board assemblies also named surface-mount technology (SMT) PCB prototypes, PCBA prototype assembly, PCB sample assembly etc. The term prototype PCB Assembly refers to a fast prototype PCBA used to test the function of new electronic designs.

The prototype PCB assembly section of our manufacturing facility has a unique layout that allows for flexible use of both automated and manual parts-loading stations. Our engineers is qualified and experienced in producing surface-mount (SMT), through-hole (THT) and mixed-technology components and fine-pitch parts and ball grid arrays (BGAs) for high-density FR-4 PCBs.

Haina Lean Company is a professional PCB and PCBA manufacturer. We are strong, trustworthy, abiding by contracts, and guaranteeing products' quality.


PCB CAPABILITIES


FACTORY CAPABILITIES
No.Items20192020
1HDI CapabilitiesHDI ELIC (4+2+4)HDI ELIC(5+2+5)
2Max layer count32L36L
3Board ThicknessCore thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mmCore thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4Min.Hole Size

Laser 0.075mm

Mechnical 0.15

Laser 0.05mm

Mechnical 0.15

5Min Line Width/Space0.035mm/0.0350.030mm/0.030mm
6Copper Thickness1/3oz-4oz1/3oz-6oz
7Size Max Panel size700x610mm700x610mm
8Registration Accuracy+/-0.05mm+/-0.05mm
9Routing Accuracy+/-0.075mm+/-0.05mm
10Min.BGA PAD0.15mm0.125mm
11Max Aspect Ratio10:110:1
12Bow and Twist0.50%0.50%
13Impedance Control Tolerance+/-8%+/-5%
14Daily output3,000m2 (Max capacity of equipment)4,000m2 (Max capacity of equipment)
15Surface FinishingHASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16Raw MaterialFR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI

PCBA CAPABILITIES


PCBA Capability
Material TypeItemMinMax
PCBDimension (length,width,height.mm)50*40*0.38600*400*4.2
MaterialFR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
Surface finishHASL,OSP,Immersion gold,Flash Gold Finger
ComponentsChip&IC100555mm
BGA Pitch0.3mm-
QFP Pitch0.3mm-


PCB Assembly Prototype Delivery Time


Product TypeQtyNormal lead timeQuick-turn lead time
SMT+DIP1-501WD-2WD8H
SMT+DIP51-2002WD-3WD1.5WD
SMT+DIP201-20003WD-4WD2WD
SMT+DIP≥20014WD-5WD3WD
PCBA(2-4Layer)1-502.5WD-3.5WD1WD
PCBA(2-4Layer)51-20005WD-6WD2.5WD
PCBA(2-4Layer)≥2001≥7WD5WD
PCBA(6-10Layer)1-503WD-4WD2.5WD
PCBA(6-10Layer)51-20007WD-8WD6WD
PCBA(10-HDILayer)1-507WD-9WD5WD
PCBA(10-HDILayer)51-20009WD-11WD7WD

PCB Assembly Prototype Application Field


Our products are widely used in communication equipment, industrial control, consumer electronics, medical equipment, aerospace, light-emitting diode lighting, automotive electronics.



Workshop



PCB Assembly Prototype Common packaging


PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box



FAQ


1.What are needed for quotation?
PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ......)
PCBA: PCB information, BOM, (Testing documents...)

2. What file formats do you accept for production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

3.Are my files safe?
Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third party.

4.MOQ?
There is no MOQ .We can flexibly handle small and mass production.

5.Shipping Cost ?

The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .

6.How to ensure high-quality production?
The process is strictly controlled under ISO 9001:2015 standards.
Most of our advanced equipment and tools are imported from abroad. Such as Flying Probe, X-ray Inspection, AOI (Automated Optical Inspector) and ICT (in-circuit testing).
We have a very professional QC team.

Q7.What are the services you can provide ?

One-stop contract manufacturing
A:PCB Assembly;
B:PCB Design & Layout
C:PCBA programming & functional testing;
D:Electronic components purchasing service;
E:Enclosure molding & final assembly with labels,instructions,enclosure, boxes.

Q8.Whether all PCBA s will be tested before delivery ?

Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .

Q9.Do you provide OEM service ?

Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .


Company Information


Haina lean Electronics Co., Ltd is a one-stop EMS supplier integrating PCB design, PCB manufacturing, Component sourcing and PCB assembly.

Our company was established in May 1, 2012 in Beijing. And expansion was completed in June 2016. The company is specialized in electronic products supporting processing services, mainly to undertake circuit board design, layout production, components procurement, PCB plate making, circuit board welding assembly debugging and other OEM/ODM services.
