PCB Mount Ct Current Transformer 1mA 5mA Fully Enclosed

PCB Mount High-Precision Current Sensing Transformer

PCB Mount Type current sensing transformer A current transformer (CT) is a type of transformer that is used to measure alternating current (AC). It produces a current in its secondary which is proportional to the current in its primary. Current transformers, along with voltage or potential transformers, are instrument transformers. Instrument transformers scale the large values of voltage or current to small, standardized values that are easy to handle for measuring instruments and protective relays. The instrument transformers isolate measurement or protection circuits from the high voltage of the primary system. A current transformer provides a secondary current that is accurately proportional to the current flowing in its primary. The current transformer presents a negligible load to the primary circuit.

Applications :

• Residual current circuit breaker
• Earth Leakage protection switch
• Leakage circuit protection Breaker
• Leakage circuit protection plug (Appliance Leakage Circuit Interrupter -ALCI)
• Current transformer can play the role of current conversion and electrical isolation.
• If the secondary fault occurs, it will not affect the (primary) main line operation, reducing the frequency of maintenance
• According to the design of the circuit, the transformer will be more in line with the operation needs of the product.

Features:

• Low profile, compact size, Epoxy resin encapsulated, fully enclosed.
• PCB mounting type, easy to fix and install.
• Wide linearity range for output current and low phase shift error.
• Customer specifications are available.
• Used in universal and be in good interchangeability.

Notes: Product specifications can be customized

    Shaanxi Shinhom Enterprise Co.,Ltd is one large-sized key enterprise in producing magnetic components and supplying OEM`high quality magnetics components in China ,It has been approved for the certification ISO9001&QS9000.Shinhom has grown rapidly by supplying high quality magnetic components on-time, offering competitive pricing, and providing strong customer service, It`s products can be widely used in personal computer, computer peripherals, automotive electronics, consumer electronics, elecommunication equipment ,test equipment, GPS equipment, medical appliances and cellular Phone to name just a few . It has annual capacity reaches 300 Million Pieces and has more than 20 year of experience in producing inductors & transformers,Current transformers, filters.

    Since its inception in 1998, shinhom has become a major supplier of inductors & transformers and Product Solutions for its professional R&D Department, accurate market positioning and high quality products.
