IOT Smart DC2.5V 2 Port Valve Motor DN15 PN10 Heating Control

Categories Zone Valve Motor
Brand Name: Runpaq
Model Number: K32
Certification: NONE
Place of Origin: China
MOQ: 1000 pieces
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 200000 sets/month
Delivery Time: 15-21 days
Packaging Details: carton
Normal voltage: 2.5VDC-5V DC battery
Application: open / close heating control ball valve
Empty run current: <40 mA (23 C)
Current at full loading: about 650 mA (motor #300)
Motor: DC2.5V-DC5V
Torque: 2 NM (2000:1)
Open / close time: < 10 S (2000:1)
Reduction ratio: 2000 : 1 (For DN15 - 20 - 25 ball valve);
Model: K32
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

IOT Smart DC2.5V 2 Port Valve Motor DN15 PN10 Heating Control

DC2.5V motor actuator, 2 way brass ball valve dN15, PN10


Product description

You'll get a wide selection of spare parts for your products in the application on HVAC, automation, IOT smart city, zone control valve, heating valve, AMR water meter, etc. A mini motorized ball valve, can be 2 way or 3 way full port, which are used for the flow control, zone valve, heating valve control, smart water meter open / close. The robust structure, ensures extremely long service life cycles more than 20,000 times, also different protection level. The brass ball valve need be driven to be open or close, or an open angle by a DC motor actuator. Our DC synchronized gear actuator motors are available with DC2.5V-5V lithium powered, torque: 1NM - 9 NM at different velocity reduction ratio.


Technical data-Model K32
1. Voltage: DC3.6 V (Range: DC2.5 - 5 V, the higher the voltage, the larger torque, the shorter life span)
2. Current at idle: <40 mA @ 3.6V, 23ºC
3. Current with max loading: <650 mA (motor #300)
4. Torque: >2 NM (2000:1)
5. Open/close time: <10 S (2000:1)
6. Velocity reduction ratio: for DN15, DN20, DN25 ball valve (2000:1)
7. Protection: IP67

Wiring definition

NoColor of wireDefinition
4blackpositive (+)
5rednegative (-)

Production overview
