| Categories | Wedge Screen Filter |
|---|---|
| Brand Name: | STD |
| Model Number: | STD-FC |
| Certification: | API, ISO, CE, QMS, IAF, IADC |
| Place of Origin: | HeBei，China |
| MOQ: | 1 |
| Price: | To be negotiated |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 pieces per day |
| Delivery Time: | 5-8word days |
| Packaging Details: | Carton/Wooden tray/Wooden box |
| Name: | Wedge wire filter |
| Type: | Filter Cylinder |
| Hole Shape: | Round |
| Thickness: | 0.35-0.5mm |
| Width: | Customize Size |
| Material: | 304 stainless steel |
| Filter Rating: | 99% |
| Length: | Requirement |
| Application: | Food & Beverage Factory, Koi Pond |
| Usage: | Liquid Filter |
| Size: | 0.2-6mm or customized |
| Color: | Silver |
OEM Customized Wedge Wire Screen Cylinders And Other Wedge Wire Filters
The wedge-shaped wire mesh filter element is made of stainless steel wedge-shaped wire mesh. The filter grade is 25 to 500 microns, and it can separate solids and suspended matter (including feces, food waste and other organic water) over 30μm from the water. As the water flows through the sieve, the particles are filtered. The rinsing system automatically flushes waste from the screen and keeps the drum running efficiently. They have the characteristics of good strength, high wear resistance, wear and corrosion resistance, uniform clearance, good filterability and fluidity, and easy cleaning and backwashing.
1. Temperature : up to 300℃
2. Micron rating:Up to 20micron
3. Material: SS304, SS316,SS316L
4. Easy to clean , backwash avaliable
5. High ridity resistance to abrasion and corrosion
6. Application:Wedge wire filter elements are used in sieving of petroleum,chemical industry, pharmaceutics, food and beverage, metallurgy and coal, also can be used in filtration of water treatment.
7. OEM &ODM AVALIABLE
| Material | SS304, SS304L, SS316, SS316L, SS321, Duplex, Hastelloy, etc | ||||
| OD Range | According to request and the actual flange and strengthen bar | ||||
| Normal ID | 176mm, 200mm, 230mm, 255mm. According to request | ||||
| Normal Length | 600mm, 602mm, According to request | ||||
| Normal Slot | 0.21mm, 0.4mm, 0.41mm, 0.8mm. Customized 0.02-3mm. | ||||
| Slot Direction | Radial Direction | ||||
| Wedge Wire | 0.75x1.5 | 1x2 | 2x3 | 2*4 | 3*5 |
| Support Rod | 1.5x2.5 2x3 | 1.5x2.5 2x3 | 2x3 2x4 3x5 3x6 | 2x4 3x5 3x6 5x6 | 3x5 3x6 5x6 |
| End Finishing | Flange, Metal Ring, etc | ||||
| Note | Customized According To Requirement | ||||
The Delivery:
|
