Uncooled LWIR Camera Module Core 640x512 / 17μm Strong Environmental Adaptability

Categories Thermal Camera Core
Brand Name: GST
Model Number: PLUG617R
Certification: ISO9001:2015; RoHS; Reach
Place of Origin: Wuhan, Hubei Province, China
MOQ: 1 Piece
Price: Negotiable
Payment Terms: L/C, T/T
Resolution: 640x512/17μm
NETD: <30mK
Spectral Range: 8~14μm
Size: 44.5x44.5x33.6mm
Weight: <90g
Frame Rate: 25Hz/30Hz
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Uncooled LWIR Camera Module Core 640x512 / 17μm Strong Environmental Adaptability

PLUG617R Uncooled Thermal Camera Module

Uncooled LWIR VOx 640x512 / 17μm Infrared Thermal Module, Thermal Imaging Camera Core


Product Description

PLUG617R is one of the PLUG series uncooled thermal camera module developed by Global Sensor Technology (GST). It consists of 640x512 / 17μm uncooled fpa infrared detector, full series of optical components, professional signal processing circuit and image processing algorithm.


PLUG617R infrared thermal sensor module is a kind of uncooled camera module applied in the field of industrial thermal imaging and temperature measurement. The temperature range is customizable, which can meet the specific requirements of industrial thermography and present a clear thermal image.


As a leading thermal camera module manufacturers, Global Sensor technology is committed to opening a new vision for industrial temperature measurement. After years of technical accumulation and practical experience in the field of infrared temperature measurement, we have provided our customers a full range of machine thermal imaging vision solutions.


Main Features


- NETD<30mk, High Sensitivity
- Stable Performance
- Easy Integration
- Clear Image Quality & Details
- Customizable Temperature Range
- Strong Environmental Adaptability


Product Specifications

ModelPLUG617R
IR Detector Performance
Resolution640x512
Pixel Pitch17μm
Spectral Range8~14μm
NETD<30mk
Image Processing
Frame Rate25Hz/30Hz
Start-up Time<15s
Analog VideoPAL/NTSC
Digital VideoRAW/YUV/BT656/LVDS
Extension ComponentUSB/Camerlink
Dimming ModeLinear/Histogram/Mixed
Digital Zoom1~8X Continual Zoom, Step Size 1/8
Image DisplayBlack Hot/White Hot/Pseudo Color
Image DirectionHorizontally/Vertically/Diagonally Flip
Image AlgorithmNUC/AGC/IDE
Electrical Specification
Standard External Interface50pin_HRS Interface
Communication ModeRS232-TTL, 115200bps
Supply Voltage4~6V
Temperature Measurement
Operating Temperature Range-10°C~50°C
Temperature Range-20°C~150°C, 100°C~550°C
Temperature Accuracy±2°C or ±2% (Take the Maximum Value)
SDKARM/Windows/Linux SDK, Full Screen Thermography
Physical Characteristics
Dimension (mm)44.5x44.5x36.6
Weight<90g
Environmental Adaptation
Operation Temperature-40°C ~ +70°C
Storage Temperature-45°C ~ +85°C
Humidity5%~95%, Non-condensing
VibrationRandom Vibration 5.35grms, 3 Axis
ShockHalf-sine Wave, 40g/11ms, 3 Axis 6 Direction
Optics
Optional LensFixed Focus Athermal: 7.5mm/13mm/19mm/25mm/35mm
Motorized Lens: 75mm/100mm/150mm

Industrial Applications

The PLUG617R infrared thermal module is widely used in Electric Power Inspection, Machine Vision, Building HVAC Security & Monitoring, Outdoors, Firefighting & Rescue, Law Enforcement & Rescue, ADAS, UAV Payloads etc.



About GST Infrared


FAQs

1. What are the advantages of uncooled infrared detectors?

Uncooled infrared focal plane detector does not need cooled device, it can work at room temperature and has the advantages of fast start, low power consumption, small size, light weight, long life, low cost and so on.


2. What are the key considerations on an infrared detector / thermal module for your application?

---The detector resolution

---The pixel size

---The NETD

---The image quality

---The lens options

---The power consumption

---The size and weight

---The mechanical & electrical interface

---The budget
