LWIR 640X512 / 12μm Uncooled Infrared Module Integrated in Thermal Imager, Infrared Camera

COIN612/R infrared thermal camera module adopts state-of-the-art 12μm VOx microbolometer technology and integrates 640x512 wafer level package (WLP) infrared thermal detector. It features in precise visualization and crisp image presentation, compact size and low cost.

The COIN612/R thermal camera core has an optional thermographic function with measurement range from -20℃~550. Its infrared radiometric measurement derives a more precise and more credible result than thermocouples on the measurements of temperature field.

Thanks to its fully optimized structure, low power consumption and various standard interfaces, COIN612 infrared camera module can provide customers with some standard configurations. Also some customized OEM solutions are available to meet the requirements of customers. It is easily integrate into many kinds of devices like unmanned aerial vehicles (UAV), drones, as well as police and firefighting units.

- Sharp & crisp thermal imaging presentation
- Precise temperature measurement
- A variety of successful integration solutions
- Multiple standard interfaces for easy integration

The COIN612/R uncooled VOx LWIR infrared sensor module is widely used in Thermography, Security & Monitoring, Outdoors, Firefighting & Rescue, AIoT, Intelligent Hardware, UAV Payloads, ADAS etc.

1. What is infrared thermal imaging?

Infrared thermal imaging is a kind of method which utilizes infrared radiation and thermal energy to gather information about objects. According to the radiation difference between the object and the background environment and the radiation difference of each part of the object itself, the infrared thermal image can show the radiation fluctuation of each part of the scene, thus showing the characteristics of the scene.

2. What is the advantage of infrared thermal imaging?

---See through total darkness;

---Identification under camouflage;

---Long range detection;

---Heat distribution detection;

---Non-contact temperature measurement;

---Occupation awareness

3. What is the applications of infrared thermal imaging?

Temperature measurement and all-weather imaging are two basic functions of infrared thermal imaging technology. Products developed based on these two technologies are widely used in electric power, security & monitoring, industrial manufacturing, scientific research, medical treatment and other traditional fields.
