Categories | Stainless Steel Pipe Tubing |
---|---|
Brand Name: | Rex Metal |
Place of Origin: | China |
MOQ: | 1PCS/1TON |
Price: | USD/RMB/EUR |
Payment Terms: | L/C, T/T, EXW, D/A, D/P, Western Union, MoneyGram |
Delivery Time: | 5-20days |
Packaging Details: | Standard Seaworthy Package |
Product Name: | Stainless Steel Tubing/Pipe |
Standard: | ASTM, AiSi, ASTM A269, ASTM A213. etc |
Application: | tubing in oil ,gas well,boiler |
Grade: | 300 Series, 304/304L/316/316L/321/309S/310S, etc |
Heat Treatment: | Bright Annealed |
Process Method: | Cold Drawn |
Inspection: | 100% |
Surface Finish: | Bright Annealed/ Polished |
Certification: | ISO |
Tolerance: | According Customer's Requirement |
Length: | According to The Sizes |
Certificates: | ISO9001:2008 & PED |
NDT: | Eddy Current or Hydraulic Test or UT |
Packing: | Plywood Case or Wooden Case |
Typical dimensions for aerospace applications range from 0.25 mm (0.010 in.) to
50.80 mm (2.0 in.) outside diameter.
other Stainless steel Tubing Dimension ranges :
Product Name | Executive Standard | Dimension | Steel Code / Steel Grade |
Industrial Pipes | ASTM A312, A358, A778, JIS G3459 | OD: 1/4"~40" | TP304, TP304L, TP316L, SUS304TP |
WT: SCH5S~SCH80S | |||
Tubes for Boiler and Heat-Exchanger, General Service Tubing | ASTM A249, A269, JIS G3463 | OD: 15.9~139.8mm | TP304, TP304L, TP316L, SUS304TB |
WT: 1.6~5.0mm | |||
Mechanical and Structural Tubes | ASTM A554, JIS G3446 | OD: 7.9~152.4mm | MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD SUS304 |
WT: 0.5~6.5mm | |||
Square Tubes | ASTM A554 | OD: 12.7x12.7~150x150mm | MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD |
WT: 0.7~6.5mm | |||
Rectangular Tubes | ASTM A554 | OD: 10x20~100x200mm | MT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD |
WT: 0.7~6.5mm | |||
Sanitary Tubing | ASTM A270 | OD: 25.4~165.2mm | TP304, TP304L, TP316L, SUS304TBS |
JIS G3447 | WT: 0.8~3.05mm | ||
Large Gauge Pipes for Ordinary Piping | JIS G3448 | OD: 15.88~318.5mm | SUS304TPD |
WT: 0.8~3.0mm | |||
Large Diameter Pipes | JIS G3468 | OD: 14"~40" | SUS304TPY |
WT: SCH5S~SCH40S |
Finish
Finish | Options | |||
Polished | Normal #400-#500 | #600 | Mirror #700-#800 | |
Brushed | Round lines | Straight lines | #180, 240, 320, 400 | |
Color plated | Golden | Bronze | Champagne | Rose gold |
Aplication
Packing and Shipping
Company Profile
FAQ
Q1: Are you trading company or manufacturer ?
A: We are a professional manufacturer with 20 years' experience and
have took part in international trade for 10 years.
Q2: How about your quality and how do you guarantee the quality?
A: All products we supply is primary as you need, Our company is
certificated to ISO9001: 2008, and every product will be tested for 4-5 processes. We welcome customers or the third party
inspection agencies to come to our factory for inspection.
Q3: Do you provide samples ? Is it free or extra ?
A: Yes, we could offer the sample for free charge.
Q4: How long is your delivery time?
A: For Stocks, we can send the goods to loading port within 7 days
after receiving the deposit ;
For production period, it usually needs about 15 days ~30 days
after receiving the deposit.
Q5: What is your terms of payment ?
A: Usually 30% deposit by TT in advance and balance against copy pf
BL or L/C at sight.
![]() |
