ATEX Explosion Proof Exit Emergency Lights IP66

ATEX Hazardous area LED Explosion proof Emergency Light EXIT SIGN IP66

LED Explosion Proof Emergency EXIT Light-Swordfish series

Highlight: Explosion proof Emergency EXIT Light

Features And Benefits:

1. ATEX Approved LED Explosion proof Emergency EXIT luminaire for Zone 1&Zone 2 and Zone 21&Zone 22.

2. Copper-free aluminum alloy housing plus tempered glass cover.

3. With a self-contained Ni-cd battery, battery duration time 3 hours.

4. Normal use: 18W,emergency use:5W.

5. “EXIT” Signs can be customized.

6. Over-Charging and over-discharging protection.

7. IP66.

Product Important Information:

Type Of Protection	Ex d eb ,Ex tb
Protection Standards	(IEC)EN 60079-0, (IEC)EN 60079-1, (IEC)EN 60079-7, (IEC)EN 60079-28, (IEC)EN 60079-31 EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8
Area Classfiction	Zone 1 and Zone 2 Areas to (IEC)EN 60079-10-1,Zone 21 and Zone 22 Areas to (IEC)EN 60079-10-2
Installation	(IEC)EN 60079-14
Certificate	IECEx_TUR_16.0028X/TÜV 15 ATEX 7673 X
Equipment Coding	□Ex d eb op is IIB T6 Gb ,Ex tb op is IIIC T80℃ Db □Ex d eb op is IIC T6 Gb , Ex tb op is IIIC T80℃ Db
Temperature Class	Rated power (W)		-20℃ ≤ Ta ≤ +55℃
	Normal	Emergency	Gas	Dust
	18W	5W	T6	T80℃
Battery Capacity	2.8 Ah
Battery Type	Ni-Cd
Battery Lifespan	500 cycles
Back up	180 min
Chargeing time (after full discharge)	12 hours
ATEx Coding	II 2 G / II 2 D
Ingress Protection	IP66 (IEC)EN 60529
Cable entry	M20*1.5,M25*1.5,3/4 NPT
CE Mark	The CE marking of this product applies to EU directives 2014/35/EU, 2014/30/EU, 2012/19/EU , 2011/65/EU and 2014/34/EU respectively. The Equipment is declared to meet the provisions of the ATEX directive(2014/34/EU)by reason of the EC Type Examination and compliance with the Essential Health and Safety Requirements

Applications:

This explosion proof Emergency EXIT light can be widely used in hazardous areas, such as:

petrochemical facilities

waste treatment plants

food processing

Power generation industry

Manufacturing plants

Coal and Dust Storage Areas

Power Transmission industry

Ordering information:

Remark:

1. * Stands for Exit sign type, Can be customized according to customer requirements.
