Pallet Transfer Cart Rail Transport Platform

Categories Coil Transfer Cart
Brand Name: Remarkable
Model Number: KPX/KPD
Certification: CE, ISO
Place of Origin: Henan, China
MOQ: 1
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 600
Delivery Time: 30-45 work days
Packaging Details: 1. Main body of the machine is packed with high-quality waterproof plastic cloth. 2. Electrical parts are specially protected, and the spare parts are packed in standard export fumigation free wooden boxes.
Power supply: Battery/Rail/Cable
Load: 1-1000 tons
Operation method: Wireless remote control & Hand operate pendant
Traveling speed(m/min): 0-20(Stepless speed regulation)
Other function: Exquisite Drive Module Design, Less parts and Easy maintenance
Product name: Pallet Transfer Cart Rail Transport Platform
table size: customized
Feature: Easy Operation Safety Convenience
Material: Carbon Steel
Rail And Wheel: Insulated Material Will Be Added
High Light: Warehouses Rail Transfer Cart, Material Handling Rail Transfer Cart, 20m/Min Rail Transfer Cart
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Pallet Transfer Cart Rail Transport Platform

Pallet Transfer Cart Rail Transport Platform


Pallet transfer car is powered by low voltage electricity from railways or battery-powered, the kind of transfer car is one of the most convenient and it often can be widely used in the industry field and so on. Of course, compared to other transfer equipment, its main features are as follows, its rails are insulated with the ground, and its wheels are insulated with the ground, so don't others.it is the advantage that the tracks carriage has, why we design is that its convenient (only rails needed) and its simple operation. About us, Our company have professional team and utilize more advanced technique to make it, and it has been a long year to manufacture it attentively. Simultaneously, it will be easier and more flexible. Due to no cable limitation, the running distance of the transfer vehicle is not limited, and the speed can also be adjusted as required. Simple structure and low cost make it popular for workshop transportation. The Pallet Handling Transfer Car can be applied on the occasion with any loading capacity and high using frequency.


Remarkable Pallet Handling Transfer Car not only has sold across the country but also exported to US, Germany, Thailand, Singapore, South Africa, Turkey, Sri Lanka, etc. We are a professional manufacturer of material transfer carts with more than 17 years' experience. According to your needs, we can customize manufacture transfer carts for any application. Our company passed the ISO9001 Quality management system and got the CE, SGS certificate.


Contact Us For A Free Consultation Based On Your Requirements. Remarkable Sells Its Pallet Transfer Cart Rail Transport Platform Worldwide!



Technical parameters for Battery powered electric transfer carts KPX series
ModelKPX-2tKPX-5tKPX-10tKPX-20tKPX-25tKPX-30tKPX-40tKPX-50tKPX-150t
Rated Load(t)25102025304050150
Table Size(mm)Length2000350036004000450045005000550010000
Width150020002000220022002200250025003000
Height4505005005506006006506501200
Wheel Base(mm)120025002600280032003200380042007000
Rail Inner Gauge(mm)120014351435143514351435143514352000
Wheel Diameter(mm)Ø270Ø300Ø300Ø350Ø400Ø400Ø500Ø500Ø600
Wheel Quantity444444448
Ground Clearance(mm)505050505050505075
Running Speed(m/min)0-250-250-250-200-200-200-200-200-18
Motor Power (Kw)11.21.62.233.54515
Battery Capacity (Ah)180180180180250250300330600
Battery Voltage(V)243648484848484872
Running Time When Full Load4.325.44.8443.53.63.32.9
Running Distance for One Charge (Km)6.58.17.24.84.84.24.343.2
Max Wheel Load (KN)14.425.842.677.794.5110.4142.8174266
Reference Weight(t)2.83.64.25.96.56.87.6827
Recommended Rail ModelP15P18P18P24P38P38P43P43QU100

1. Load capacity, table size, and rail gauge can be customized;
2. Options: Remote radio control (imported or made in china);
3. Automatic stop when detecting obstacle or person, limit switches (to limit travel);
4. Battery type (Free of maintenance Battery, Lithium battery, Explosion-proof battery, and Anti-high temperature battery);
5. Motor (DC motor with brush and DC motor brushless);
6. Electrical parts (imported or made in China).



Functions & Advantages Of Pallet Handling Transfer Cart


The Pallet Handling Transfer Car is Anti-high temperature, Anti-high explosion;

The Pallet Handling Transfer Car is powered by a battery or Low voltage rail power supply;

With lifting holes, Pallet Handling Transfer Car is convenient for shipment;

The Pallet Handling Transfer Car has a feature of stable start, big starting power, long lifetime;

The Pallet Handling Transfer Car can run on the C-form track or S-form track;

Running distance of Pallet Handling Transfer Car is unlimited;

Safe and convenient operation is available for Pallet Handling Transfer Car;

High using frequency for Pallet Handling Transfer Car.

Application Site


Application Sites Of Pallet Handling Transfer Car

The Pallet Handling Transfer Car is mainly applied in assembly line(ring production line,loop production line),metallurgy industry(steel lade),warehouse transport,ship industry(maintenance, assemcle,container transport),work piece transport in workshop,lathe transport,steel factory(steel billet,steel plate,steel coil,steel pipe,section steel structure),construction(bridge,simple building,concrete column,)petroleum industry(oil pump,sucker rod and parts),energy(polycrystalline silicon,generator,windmill),chemical industry(electrolytic cell,retort etc),railway(rail maintenance,rail welding,train tractor).
