Thickness 10mm-60mm Automatic Edge Banding Machine 5 functions

Categories Woodworking Edge Banding Machine
Brand Name: OSETMAC
Model Number: SYS-300
Certification: CE
Place of Origin: CHINA
MOQ: Negotiable
Price: Negotiate
Payment Terms: L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30000set per year
Delivery Time: 5-8 work days
Packaging Details: wooden case or as request
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Thickness 10mm-60mm Automatic Edge Banding Machine 5 functions

Thickness 10mm-60mm Automatic Edge Banding Machine 5 Functions


Feature


1. Adopt imported motor and high quality electrical component.

2. High precision and work efficiency.
3. Automatic and precise gluing procedure as well as integrated double finish.
4. Glue evenly, conveying stability
MODEL: SYS-300
Panel Thickness: 10-60mm
Edge Band Thickness: 0.4-3mm
Panel Width: ≥60mm
Panel Length: ≥150mm
Feeding Speed: 15m/min
Working Pressure: 0.6Mpa
Voltage: 380V/50HZ/3PH
Gluing Motor: 0.37KW 50HZ 1400RPM
End Cutting Motor: 0.37KW * 2 200HZ 12000RPM
Fine Trimming Motor: 0.75KW * 2 200HZ 12000RPM
Buffing Motor: 0.37KW * 2 50HZ 1400RPM
Conveyor Motor: 1.5KW Glue Pot Heating Power:1.5KW
Assistant Heating Power: 0.3KW Lighting Power: 0.05KW
Total Power: 6.7KW
Dimension: 3800x900x1680mm


Description:

*5 functions:Gluing--end cutting--Fine--Trimming--Scraping-Buffing

*PLC control with touch screen (141*195mm)

*Working Voltage:380v/50HZ/3PH

*Taiwan"DELTA"brand inverter,PLC Touch Screen

*The entire machine is painted in a white color

*In the machine is mounted lights
