Fodder Belt Scale Pellet Animal Feed Packing Machine Auto Lifting 11.7L/ Min PLC

Categories Animal Feed Packing Machine
Brand Name: EWINALL
Model Number: DCS-50ZH
Certification: ISO,CE,QMS,CCPIT
Place of Origin: Anhui,China
Packing range: 25kg to 50kg
Load cell: Three load cells
Control: PLC control
Sewing: Auto cutting and sewing
Conveyor: Auto Lifting
OEM: Avaliable
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Fodder Belt Scale Pellet Animal Feed Packing Machine Auto Lifting 11.7L/ Min PLC

Animal Feeds Belt Packing Scale from 25kg to 50kg

DCS-50ZH Belt Scale For Different Kinds Of Granular Grain


Scope of application

Suitable for granular materials with general fluidity.


Technical parameters

modelDCS-50ZH
Weighing range(25-50) kg
Division value10g
Weighing error±0.1%FS
Packaging capacity(120-240) packages/hour
Power/power consumptionAC380V±5% 50Hz; 1.85KW
Air source/gas consumption0.4~0.5Mpa, compressed air 11.7L/min
Ambient temperature(0~40)℃
environment humidityIt does not exceed 90%RH at 40°C,
and greater humidity is allowed at low temperatures
Length x width x height (mm)2933x1385x2544

Features

1. Unique frequency conversion speed control conveyor feeding mechanism. The frequency converter controls the power supply frequency of the conveyor motor to realize the continuous feeding of the conveyor to the metering hopper at fast, medium and slow flow rates. For granular particles with general fluidity The material can realize better feeding control, realizing quantitative feeding and packaging.

2. Conveyor automatic lifting technology, automatic bag sewing and automatic thread cutting function. Advanced functions, stable and reliable.

3. There is a manual control mode, which can control the discharging and loosening mechanism separately by manual operation, which is convenient for cleaning agglomerated and blocked materials.

4. With automatic drop correction function. Out of tolerance alarm.


The certification
