| Categories | High Speed Weigh In Motion |
|---|---|
| Brand Name: | Hengliang |
| Model Number: | ZQS-40-SY |
| Certification: | ISO |
| Place of Origin: | Zhenghou`China |
| MOQ: | 1 SET |
| Price: | USD 20000-35000/SET |
| Payment Terms: | T/T |
| Supply Ability: | 30 SET/Month |
| Delivery Time: | 5~7days |
| Packaging Details: | Wooden box |
| Type: | High Speed Weight In Motion |
| Power: | AC 220V 50Hz |
| Weighing error: | 3%~10% |
| Speed rate: | 0.5~105km/h |
| Single axle load: | 40T |
| Maximum load: | 60T (single axle) |
| Division value: | 50kg |
| MTBF: | ≥20000h |
| Temperature range: | -45~+80℃ |
| Protection level: | IP68 |
| Company Info. |
| Zhengzhou Hengliang Tech Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Off Site Dynamic Weighing System For Highway Vehicle Overload System
The dynamic weighing detection system automatically measures the axle load, axle group weight, total weight, vehicle type, flow, speed and other traffic data of all passing vehicles without affecting the normal driving of vehicles. And automatically judge whether the vehicle exceeds the limit according to the overrun standard set in the system.
Product Parameters
| Weighing accuracy | 90%~97% |
| Single axle load | 40Ton |
| Max Load | 60Ton |
| Speed | 0.5~105km/h； |
| Speed error | ≤±1km/h |
| Wheelbase error | ≤±100mm |
| Working voltage | AC 220V 50Hz |
| Output information | Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time |
| Maximum number of lanes | 8 lanes |
| Data storage | It can store up to 10000 pieces of vehicle information data |
| data interface | RJ485 |
| work environment | -45℃～80℃,0～95% |
| Confidence | ≥95% |
|
