| Categories | Wireless HD Video Transmitter |
|---|---|
| Brand Name: | Ding Shen |
| Model Number: | DS-HVT01 |
| Place of Origin: | China |
| MOQ: | 1 Set |
| Price: | Negotiation |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS per month |
| Delivery Time: | 3-7 days |
| Packaging Details: | export standard packing |
| Modulation:: | COFDM |
| Feature:: | walkie talkie |
| Data Encryption:: | AES 128 Bits |
| Video Input:: | BNC/RCA |
| Size:: | 154*86*59mm |
| Frequency:: | 300-4400MHz (option) |
| Video Resolution:: | 1920×1080P/I@60hz |
manpack military two way radio 2km wireless transmitter and
receiver
Model: DS-HVT01
Introduction of manpack military two way radio 2km wireless transmitter and receiver
manpack military two way radio 2km wireless transmitter and receiver is new generation of broadcast-quality good resolution image transmission and walkie-talkie system.
manpack military two way radio 2km wireless transmitter and receiver adopts the current leading COFDM modulation technology and relative narrow-band frequency(2/2.5//4/8MHz).
manpack military two way radio 2km wireless transmitter and receiver has the strong anti-jamming capability, which can overcome the reflection and cover caused by transmission multipath simulation technique and conventional modulation techniques, to realize high-speed photography and near real-time transmit high quality image in NLOS or complicated working conditions. Especially suitable for army training ,fire rescue, marine remote control security application.
Features of manpack military two way radio 2km wireless transmitter
and receiver
*COFDM modulation,stable transmission;
*H.264 video compression,DVD video quality;
*Video and walkie-talkie Simultaneous transmission;
*RF power can be customized, long range distance;
*Works well in NLOS and fast-moving conditions;
*LCD screen shows parameters and working status;
*Dual aerials connectors.
Specification of manpack military two way radio 2km wireless transmitter and receiver
| Name | manpack military two way radio 2km wireless transmitter and receiver |
| Frequency | 300-4400MHz (option), but only 100MHz space for user |
| RF power | 2Watt |
| Power supply | DC11-14.5V |
| Modulation | COFDM 2K QPSK |
| RF Bandwidth | 2/2.5/4/8MHz(adjustable) |
| FEC | 1/2 2/3 3/4 7/8 (option) |
| Guard Interval | 1/32 1/16 1/8 1/4(option) |
| Data Encryption | AES 128/256 Bits |
| Model: SG-VT10 | manpack military two way radio 2km wireless transmitter and receiver |
| Max speed | 450km/h |
| Video input | CVBS, SDI, MINI-SDI, HD-MI |
| Audio input | Standard Aviation plug, support two-way intercome |
| Video compression format | H.264 |
| Video Resolution | 1920*1080 |
| RF Interface | SMA*2 |
| Work environment | -40℃~70℃ |
| Transmission Distance | Appr. 1km NLOS (for law enforcement) |
| Case Material Aluminum | Black |
| Size | 154*86*59mm |
| Weight | 892g |
| Type | manpack military two way radio 2km wireless transmitter and receiver |
|
